Front Service P1.25mm High Contrast Ratio Small Pixel LED Video Wall Screen
Front Service P1.25mm High Contrast Ratio Small Pixel LED Video Wall Screen
Front Service P1.25mm High Contrast Ratio Small Pixel LED Video Wall Screen
Front Service P1.25mm High Contrast Ratio Small Pixel LED Video Wall Screen
Front Service P1.25mm High Contrast Ratio Small Pixel LED Video Wall Screen
Front Service P1.25mm High Contrast Ratio Small Pixel LED Video Wall Screen
Specifications
Brand Name :
ANWELL
Model Number :
AN-PX0.9/1.25/1.5/1.6/1.8/1.9
Certification :
CE, RoHS, CCC
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
L/C, T/T, D/P, Western Union
Delivery Time :
7 business days
Packaging Details :
Wooden case package
Product name :
P1.25 fine pixel LED screen
Application :
Stage Performance, Shopping Guide, TV Station / Studio / Conference Hall
Color: :
RGB Full color
Pixel Pitch: :
1.25MM
Screen Brightness :
800nits
Panel size :
600*337.5mm
Grey Scale :
16bits
Screen Refresh Rate :
3840Hz
Service :
front Rear Maintenance
Transport Package :
Plywood Case
Input Voltage: :
AC100-240V, 50/60Hz
Control :
Colorlight Linsn Nova
Delivery time :
7-14 business days
Warranty period :
2 full years
Description

Factory Supply HD 4K 8K P0.9/P1.25/P1.56/P1.667 Small Pitch Pixel Indoor Video Wall Advertising

1.16:9 Golden division ratio
It can be point to point spliced to the led screen of standard 720P ,1080P ,2160P , 3840P,etc.

2.Ultra high definition
It delivers a truly amazing picture with extraordinary pixels producing an image that is HD quality in an LED screen .

3.High strength Aluminum alloy material
The integral die-casting aluminum molding workmanship has provided with excellent flatness of the cabinet

4.Front serviceable led screen for better experience
The front serviceable ultra HD led screen cabinet has fully described the strength of its light weight,met the needs of small space or where the needs of the cabinet thickness is needed, enhanced the vision of the space as well as its visionary effect. it allows for easy maintenance ,saving time and labor site.

5.Ultra wide viewing angle , different experience
Both 160 from horizontal and vertical fro the viewing angle. Seeing from five directions,it would be still the natural and clear image in an led screen.

6.16bit gray scale, more natural color transition
It has almost the perfect gray scale and gives true color of the images, there will have no data loss and you could see every detail clearly.

7.high contrast ratio, highlight the details
High-end black body SMD encapsulation,excellent performance , it has outstanding performance when works on the color and has very good contrast.

Technical Specification:

OPTICAL Pixel Pitch mm 1.25mm
LED No. Per Pixel pcs/pixel 1
Brightness(Adjustment) cd/m² 800
Pixel Configuration - SMD0808/1010
Module Resolution(W*H) pixels 160*135
Cabinet Resolution(W*H) dots 480*270
Pixel Density dots/sqm 640,000
Viewing Angle(H/V) degree H160/V160
Color Depth/Number bit 16bit
Grey Scale - 65,536
ELECTRICAL Frame Frequency Hz/s 50/60
Refresh Rate Hz ≥3,840
Contrast Ratio - 5000:1
Max Power Consumption W/m² 800
Ave Power Consumption W/m² 250
Working Voltage AC AC90~264V
Drive Voltage DC 5V
Working/Storage Temperature ºC -20ºC - 60ºC
Humidity - 10%-85%RH
Driving Method - 1/30scan
MECHANICAL Frame Material - Die-casting aluminum
Module Size mm 200 * 168.75
Net Weight kg/pcs 7.8
Weight Per Tile lbs 17.21
Cabinet Size mm 600*337.5*80
IP Rating - IP30
Lifetime hours 100,000
Service Access - front
Application - Indoor

Supply Ability

Supply Ability: 1100+pieces/pcs per Month.

Packaging & Delivery

Packaging Details
LED module and accessories hard carton package
Flight case and wooden case package for cabinets.
Port
SHENZHEN CHINA
LOGO
Acceptable
Lead Time :
Quantity(Square Meters) 1 - 100 >100
Est. Time(days) 25 To be negotiated

Full HD video wall products and projects overview

Front Service P1.25mm High Contrast Ratio Small Pixel LED Video Wall Screen

OUR SERVICE:

PRE-PRODUCING:

1. Get complete requirements of clients
2. To do a thorough analysis
3. Offer a most reasonable and scientific solution
4. Customized design

IN PRODUCING:

1. Producing progress updating for clients
2. Particular Installation CAD and Design Diagram for clients

AFTER SERVICE:
1. 2 years free maintenance
2. 7 days a week, 24 hours a day for 5 years on-line service for any technical support for any customers
3. Free training for customers in factory
4. Local Partner Installation Service
