Bluetooth EV Charging Pile 400V Type 2 RFID Public Charging Stations
Bluetooth EV Charging Pile 400V Type 2 RFID Public Charging Stations
Bluetooth EV Charging Pile 400V Type 2 RFID Public Charging Stations
Bluetooth EV Charging Pile 400V Type 2 RFID Public Charging Stations
Specifications
Brand Name :
Green Science
Model Number :
GS22-AC-B01
Certification :
GB CE UL
Place of Origin :
China
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
10000 Sets Per Month
Delivery Time :
10-15Workday
Packaging Details :
570*350*310mm
Product name :
22KW 32A EV Charging Pile
Output Power :
22Kw Max
Product Price :
Negotiate
Working Voltage :
380V AC~400V AC
Warranty Time :
One Year
Work Altitude :
Below 2000m
Description

22KW 32A EV Charging Pile 400W Type2 Public Charging Stations

Quick Detail:

Model Number: GS22-AC-B01

Rated Voltage: 40V AC

Rated Current: 32A

Rated Output Power: 22kw

Charging Port: Type 2 Cable

Cable Length: 3.5M/Customized

Communication: 3G/4G/5G, WIFI or Bluetooth Optional

Start Mode: Plug and Play/RFID card/App

Function: APP Control, screen display, Voltage Monitoring

Specifications:

Product Name EV Charging Station (WallBox)
Data Model GS7-AC-BO1 GS11-AC-BO1 GS22-AC-BO1
Input Power Supply 1P+N+PE 3P+N+PE 3P+N+PE
Rated Voltage 200~220V AC 380~400V AC 380~400V AC
Rated Current 32A 16A 32A
Output Output Voltage 200~220V AC 380~400V AC 380~400V AC
Output Current 32A 16A 32A
Rated Power 7KW 11KW 22KW
Package Unit Size 340*285*147mm
Package Size 570*350*310mm 570*350*310mm 570*350*310mm
Net Weight 3.8KGS 4.5KGS 4.5KGS
Gross Weight 6.5KGS 6.5KGS 6.5KGS
Communication WIFI Optional
3G/4G/5G Optional
OCPP OCPP 1.6 Json (OCPP 2.0 Optional)
User Interface Charging Port Type 1/ Type 2
Cable Length 3.5M or customization length
LED Indicator White/Green/Black/Blue/Orange/Purple/Customized
Start Mode Plug&Play / RFID Card / APP
Emergency Stop YES
Environment Installation Wall-mounted Pole Mounted
Work Temperature -25℃-+50℃
Work Humidity 5%-95%
Work Altitude <2000M

Bluetooth EV Charging Pile 400V Type 2 RFID Public Charging Stations

Steps for adding APP device Download method:

For IOS: Search Smart Life in the Apple Store to downtoad and install it.

For Android: Search Smart Life in the Google Stare to download and install it.

Step 1 Add Device: Click "Add Device"

Step 2 Connect the WIFI: When adding a device for the first time, connect the device and mobile phone under the same WIFI.

Step 3 Loading: Wait until the device is loaded.

Step 4 Loading completed: After loading, click Add to enter the charging interface.

Why Choose Us?

1. More competitive price

Integrated R&D production and sales in one, can supply more competitive price for customer.

2. Efficient Production capacity

Our employees are all skilled and experienced, who can produce substantial qualified products in a shorter time, which minimize the lead time of customer order.

3. Customization support

Outer shell shape color customization available and logo customization available Etc, which meeting a large variety of customization request of customers.

4. Easy to operate

Factory pre-commissioning of network settings– ready to connect out-of-the-box.

5. High quality and complete after-sales service.
