Specifications
Brand Name :
Frondent or OEM
Model Number :
NFC Reader 02
Certification :
CE,ROSH,ISO
Place of Origin :
China
MOQ :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
80000000/year
Delivery Time :
3-8 working days
Packaging Details :
100pcs/bag,2000pcs/carton
Material :
ABS,hard plastic/PVC
Frequency :
900-960MHz
Application :
car parking,apartment control,campus,transportation
Interface :
3.5mm 4-pole audio jack
Power Voltage :
3.2 to 3.7 V DC
0~30dBm, Software controllable :
0~30dBm, Software controllable
Read Distance :
Up to 50mm (depending on the tag type)
Work System :
Windows8\7\XP\98\2000\CE\ME\NT\LIUNX\Vista Supported
Power :
Lithium-ion battery (rechargeable through USB)
Description

Mini NFC Magnetic Bank RFID Card Reader With ISO Android SDK ACR35 Contactless White Color Lightweight Card Writer

ACR35 NFC MobileMate Card Reader is the perfect tool that you can use with your mobile device. Combining two card technologies into one.
With a rechargeable Lithium-ion battery and standard 3.5 mm audio jack interface, the ACR35 NFC MobileMate can seamlessly extend the usefulness of any mobile device. It delivers NFC reader functionality and mobility, which allows you to use NFC and contactless applications, even for mobile readers without built-in NFC functionality.
ACR35 NFC MobileMate uses AES-128 encryption algorithm to secure your data.
Portable. Modern. Versatile. Compact. ACR35 NFC MobileaMate is a handy and lightweight card reader that is perfect for users who wish to transact securely while on the go.
Should you wish to try out the demo apps for ACR32, please download the app from Google Play and App Store.

Features:
3.5 mm Audio Jack Interface
Powered by a Lithium-ion battery (rechargeable through PC-linked mode)
Smart Card Reader:
Built-in antenna for contactless tag access, with reading distance of up to 50mm (depending on tag type)
Supports ISO 14443 Part 4 Type A and B cards
o Supports MI
o Supports FeliCa
o Supports ISO 18092 Tags (NFC Tags)*
o Built-in anti-collision feature
o NFC Support:
§ Card reader/writer mode
o Capable of bidirectional reading
o Supports AES128 encryption algorithm

Application:
Mobile Banking & Payment
e-Healthcare
e-Purse & Loyalty

Tech Specs:

Dimensions 60.0mm (L) x 45.0mm (W) x 13.3mm (H)
Interface 3.5mm 4-pole audio jack
Operating Distance Up to 50mm (depending on the tag type)
Power Lithium-ion battery (rechargeable through USB)
Supply Voltage 3.2 to 3.7 V DC
Supply Current 85 mA
Operating Temperature 0-50C
Smart Card Interface Support

· ISO 14443 Part 4 Type A and B cards
· M1
· FeliCa
· ISO 18092 Tags (NFC Tags) (except Topaz type)

Compliance / Certifications ISO14443, ISO/IEC 18092, CE, FCC, VCCI, RoHS 2, REACH
Operating System Support

· Android 2.0 and above
· iOS 5.0 and above

Supported Mobile Device For the full list of supported devices, please contact our

Mini NFC Magnetic Bank RFID Card Reader With ISO Android SDK ACR35 Contactless White Color Lightweight Card Writer

Driver For ACR35

Release Date Drivers OS Support Version
04-Sep-2014 ANDROID Library (Beta) Android 2.0 and above 1.0.0.13
04-Sep-2014 iOS Library (Beta) iOS 5.0 and above 1.0.0.8

Application

  • Home Banking and Home Shopping
  • E-commerce
  • Checking the balance of electronic purses
  • Network access control
  • Customer Loyalty Program
  • Identification and Authentication
  • Ticketing
  • Online gaming
  • Parking and toll collection
  • Automatic Fare Collection
  • Public Transportation Terminals
  • Physical Access Control
  • Time attendance
  • Vending machines
  • Contactless public phones
  • Logistics and supply chain management

Mini NFC Magnetic Bank RFID Card Reader With ISO Android SDK ACR35 Contactless White Color Lightweight Card Writer

Packing & Delivery

Mini NFC Magnetic Bank RFID Card Reader With ISO Android SDK ACR35 Contactless White Color Lightweight Card Writer

Mini NFC Magnetic Bank RFID Card Reader With ISO Android SDK ACR35 Contactless White Color Lightweight Card Writer

About Us

1. FRODENT is a market leader for RFID devices supplying in China for more than10 years.

2.QUALITY IS OUR CULTURE.

3.We provide 24*7 services.

4.We will sign contract with you in each transaction to ensure the quality and deliver time.

5.We will full refund if quality is bad and we will give you compensation if we deliver your deliver.

Mini NFC Magnetic Bank RFID Card Reader With ISO Android SDK ACR35 Contactless White Color Lightweight Card Writer

Mini NFC Magnetic Bank RFID Card Reader With ISO Android SDK ACR35 Contactless White Color Lightweight Card Writer

FAQ

Q: Are you trading company or manufacturer?
A: We are factory with trading department

Q: How long is your delivery time?
A: Generally it is 7-10 days if the goods are in stock. Or it is 10-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment?
A: 30% T/T in advance ,balance before shippment.

If you have another question, pls feel free to contact us.
