BOE 5 Inch TFT LCD Display Module For Mobile Handheld Devices High Resolution
BOE 5 Inch TFT LCD Display Module For Mobile Handheld Devices High Resolution
BOE 5 Inch TFT LCD Display Module For Mobile Handheld Devices High Resolution
BOE 5 Inch TFT LCD Display Module For Mobile Handheld Devices High Resolution
Specifications
Brand Name :
XTY
Model Number :
5 " BOE 40PIN
Certification :
SGS REACH ISO9001:2008
Place of Origin :
China
MOQ :
1
Payment Terms :
0.03
Product model :
TB050-F4012N49c-00
Rasolution :
480RGB(H)×272(V)mm
Operation Temperature :
-20℃～+70℃
Storage Temperature :
-30~+80℃
Interface :
TTL 40Pin
Price :
0.03~0.1
Packaging Details :
200pcs/bag
Delivery Time :
7days
Supply Ability :
5.05
Description

China Manufacturer TFT LCD Display Module Type 5 inch BOE

Product Application

Interface

Vehicle display

Mobile handheld devices

product features

LCD size 5.0 inch(Diagonal)
Outline dimensions 120.9×75.95×2.9(Typ)mm
Rasolution 480RGB(H)×272(V)mm
Active area 110.8(H)×62.82(V)mm
Pixel pitch 0.077(H)×0.231(V)mm
Interface TTL 40Pin
Rubbing direction 6 o'clock
Operation Temperature -20℃～+70℃
Storage Temperature -30℃～+80℃
Supply voltage of backlight 18.6V～19.8V
Current for backlight 40～45mA
Luminancel (on the module surface,BM-7) 500～550cd/㎡

Product Advantage

1. Our products are all original and new from manufacturer. It must be work if the model number is correct.

2. We have advanced testing equipments
3. Get the international standard management sysem ISO9001,RoHS
4. All products before sending client,we make 72 hours aging test
5. We have 180days warranty
6. During the guarantee period, if the items you purchased from our store are out of perfected quality, pls notify us within 3 days after delivery, we will return the new products when we got your message.

Selling point:
1) prompt delivery
2) variety of packing:bulk and carton
3) stable performance,extensive resistance
4) factory direct price
5) none forbidden
6) all materials&machines importer
