L5150GJTR LDO Regulator Pos 5V 0.15A Automotive 12 Pin Power SSO EP T/R RoHS Compliant
L5150GJTR LDO Regulator Pos 5V 0.15A Automotive 12 Pin Power SSO EP T/R RoHS Compliant
Specifications
Brand Name :
STMicroelectronics
Model Number :
L5150GJTR
Certification :
Original Part
Place of Origin :
Shenzhen, China
MOQ :
1PCS
Price :
to be Negotiated
Payment Terms :
T/T, Western Union, Paypal, Wechat Pay
Supply Ability :
1 Million pieces per Month
Delivery Time :
Immediate
Packaging Details :
PowerSSO
Packaging :
PowerSSO
Product Type :
LDO Regulator Pos 5V 0.15A Automotive 12-Pin PowerSSO EP T/R
Type :
Logic ICs,Voltage Regulator
Condition :
Original 100%
Lead free status :
RoHS Compliant
Description :
Electronic Component
Description

L5150GJTR LDO Regulator Pos 5V 0.15A Automotive 12-Pin PowerSSO EP T/R

Description :

L5150GJ is a low dropout linear regulator with microprocessor control functions such as power on reset, low voltage reset, early warning, on/off control. Typical quiescent current is 55μA in very low output current mode and enabled regulator. It drops to 5μA with not enabled regulator. On chip trimming results in high output voltage accuracy (2%). Accuracy is kept over wide temperature range, line and load variation. Early warning circuit monitors the input voltage and compares it with an internal voltage reference. Output voltage reset threshold can be adjusted down to 3.5V by means of an external voltage divider.The maximum input voltage is 40V. The max output current is internally limited. Internal temperature protection disables the voltage regulator output. In addition, only low-value ceramic capacitor on output is required for stability..

Features :

  • Operating DC supply voltage range 5.6 V to 40 V
  • Low dropout voltage
  • Low quiescent current consumption
  • Precision output voltage 5 V +/- 2%
  • Reset circuit sensing the output voltage
  • Programmable reset pulse delay with external capacitor
  • Adjustable reset threshold
  • Early warning
  • Very wide stability range with low value output capacitor
  • Thermal shutdown and short-circuit protection
  • Wide temperature range (Tj= -40 °C to 150 °C)
  • Enable input for enabling / disabling the voltage regulator

Applications :

• Battery-powered applications

• Portable devices

• Signal conditioning and active filtering

• Medical instrumentation

• Automotive applications


Distinctive Characteristics :

Part No: L5150GJTR

Description: LDO Regulator Pos 5V 0.15A Automotive 12-Pin PowerSSO EP T/R

for product datasheet, CONTACT US directly
