HD LED Display Indoor Full Color Screen Small Pixel Pitch P1.667 360000 dot/㎡
HD LED Display Indoor Full Color Screen Small Pixel Pitch P1.667 360000 dot/㎡
HD LED Display Indoor Full Color Screen Small Pixel Pitch P1.667 360000 dot/㎡
HD LED Display Indoor Full Color Screen Small Pixel Pitch P1.667 360000 dot/㎡
HD LED Display Indoor Full Color Screen Small Pixel Pitch P1.667 360000 dot/㎡
HD LED Display Indoor Full Color Screen Small Pixel Pitch P1.667 360000 dot/㎡
HD LED Display Indoor Full Color Screen Small Pixel Pitch P1.667 360000 dot/㎡
HD LED Display Indoor Full Color Screen Small Pixel Pitch P1.667 360000 dot/㎡
Specifications
Brand Name :
Dehao
Model Number :
P1.667
Certification :
CE ROHS FCC
Place of Origin :
Shenzhen,China
MOQ :
1 square meter
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
2500 square meters per month
Delivery Time :
20-30 working days after deposit
Packaging Details :
Standard wooden case or flight case packing as customer's request
Pitch :
1.667mm
Density :
360000 dot/㎡
Module size :
200x150 mm
Module resolution :
120x90 dot
LED standard :
SMD1010
Brightness :
≥800 cd/㎡
Viewing distance :
1.667-15 m
Warranty period :
2 years
Description

P1.667 HD LED Display Screen,Indoor Full Color P1.667 LED Display,Small Pixel Pitch


Product Description

P1.667/1.923 Indoor Small Pixel Pitch rental LED Display screen
1.Parameter:
1.LED Module
Dot Pitch(mm) 1.667mm Size(W×H) 200*150mm
Pixel Point(Dot/ m2) 360000 dots/㎡ Resolution(W×H) 120 * 90 dots
2.LED Lamp: HuaTian
3. Rental Cabinet or Wall Frame
Module sizes 200*150mm
Cabinet Size(W×H) 400mm * 300mm
Module Weight(g/pcs) About 600g/pcs
4.Led Display Specification
ITME SPECIFICATION
LED Display Best View distance:1.667~15m
Viewing angle-Horizontal :160 degree;
Viewing angle-Vertical :110 degree
Environment Temp: -40ºC ~ +85ºC
Working Temp: -20ºC ~ +50ºC
Operating Humidity Range:≤10~95%
Power Supply Operating Voltage: 220V±5%
Average Power: 400W/m2
Max Power: 900W/m2
Control System Linsn/ Nova/ HuIdo
Main Technical Parameter Full white brightness:≥800nits
Driving IC:MBI5124 Led Driver
Scan mode:1/30 scan
Frame frequency:≥60 HZ/s
Refresh rate:≥960 HZ/s
Grey scale levels/Color processing:65536levels, Process 16.7M colors
Brightness adjustment mode: 100 levels available
MTBF:≥10,000 hours
Life-span:100,000 hours
Flatness:neighbor pixel≤0.5mm;module joint gap<1mm ;


2. Product Features:
1) High brightness(>800cd/㎡ ), adjustable.
2) Clear vivid image quality.
3) Good Raw Materials: Nationstar/ Epistar/ Chipone led chip, Nationstar led lamp, MBI IC, G-energy /CL/ Meanwel Power Supply, Meanwel/ ADDA fan, Beijing/ Korean glue.
4) Installation is simple by fast lock.
5) High stability and long span: Aging test at least 24 hours before shipment, 100, 000 hours life span.
6) Cabinet: Diecasting aluminum rental cabinets 640*640mm or standard iron waterproof 960*960 cabinets.
7) Package: Flight case, wooden box package & carton box and so on.
8) Guarantee:2 years.

3. Application Case:
Our full color LED display are widely used in commercial advertising, entertainment industry, financial industry,communications, power sector, traffic, stadium, plaza, school, airport, bus station etc. for advertising and displaying messages.
HD LED Display Indoor Full Color Screen Small Pixel Pitch P1.667 360000 dot/㎡
HD LED Display Indoor Full Color Screen Small Pixel Pitch P1.667 360000 dot/㎡

3.Products list

1)P2.5/ P3/P4/P5/P6...Indoor full color led display;
2)P10/P12/P12.5/P16/P20/P25...Outdoor full color led screen;
3)Indoor/outdoor/semi-outdoor single/dual color led panel etc.

We would like to know more details before offering you the best quotation.
1)What is screen size and what cabinet you prefer.
2)What is the best viewing distance with your project.
3) For fixed or rental installation.
4)When do you need to get goods and is it urgent or not.
5) Any special requests such as video processor, hanging bar, flight case for package.

4. Our services:
1) Your inquiry will be replied within 24 hours.
2) 2 years for warranty, service time: 24 hours*7 days.
3) Aging test at least 24 hours before shipment.
4) Factory and product inspection accepted.

5. Trade Terms:
1) Packing: Anti-shaking wooden cabinet /Air flight case/carton.
2) Shipping port: Shenzhen. China.
3) Shipping freights are quoted according to your requests.
4) Delivery time:15-25 working days.

6.FAQ:

1) Are you manufacturer? If yes, in which city?
Yes, we're factory with 4000 square meters. And we're in Shenzhen city,Guangdong Province.
2) Can I visit your factory?
We warmly welcome customers visit us. Before you come here, please kindly tell me your schedule, we can arrange for you. We specialize in producing and developing all kinds of led displays. As a reliable LED Display manufacturer and exporter in China, we supply Indoor led displays, Outdoor led displays, semi-outdoor led displays. Please kindly tell me which kind of the item you prefer to and provide me more information. It will help us to give you a good price.
