Indoor P4.81 Full Color Rental LED Display With Die-casting Aluminum Cabinet 500x1000mm
Indoor P4.81 Full Color Rental LED Display With Die-casting Aluminum Cabinet 500x1000mm
Indoor P4.81 Full Color Rental LED Display With Die-casting Aluminum Cabinet 500x1000mm
Indoor P4.81 Full Color Rental LED Display With Die-casting Aluminum Cabinet 500x1000mm
Indoor P4.81 Full Color Rental LED Display With Die-casting Aluminum Cabinet 500x1000mm
Indoor P4.81 Full Color Rental LED Display With Die-casting Aluminum Cabinet 500x1000mm
Indoor P4.81 Full Color Rental LED Display With Die-casting Aluminum Cabinet 500x1000mm
Indoor P4.81 Full Color Rental LED Display With Die-casting Aluminum Cabinet 500x1000mm
Specifications
Brand Name :
Dehao
Model Number :
P4.81
Certification :
CE ROHS FCC
Place of Origin :
Shenzhen,China
Payment Terms :
T/T, Western Union, MoneyGram
Delivery Time :
12-15 working days after payment
Packaging Details :
Standard wooden case or flight case packing as customer's request
MOQ :
10 square meters
Price :
Negotiation
Supply Ability :
3000 square meters per month
Pitch :
4.81mm
Density :
43222 dot/㎡
Module size :
250x250mm
Module resolution :
52x52 dots
LED standard :
SMD2121
Brightness :
≥1000 cd/sqm
Viewing distance :
4.81-50m
Warranty period :
2 years
Description

Indoor P4.81 Full Color Rental LED Display With Die-casting Aluminum Cabinet 500x1000mm

Product Description

Technical Parameter

LED Light Parameter

LED LED brand LED type wave Length(nm) Average Brightness
(mcd)		 Test Condition
Red(R) Sanan SMD
2121		 615-625nm 150-300mcd 25ºC,20mA
Green(G) Huacan 515-535nm 350-550mcd 25ºC,10mA
Blue(B) Huacan 465-475nm 50-85mcd 25ºC,5mA
Pixel/Module
No Item Parameter
1 Pixel Pitch 4.81mm
2 Pixel Configuration 1R1G1B / R:G:B=3:6:1
3 LED Lamp Full color
4 Density 43222dot/m2
5 Module Size 250*250mm
6 Module Pixel 52*52=2704dot
7 Module Thickness 15mm
8 Module Weight 690g
9 Module Power ≤48.5W
10 Drive Valtage DC5V
11 Module Electric Current 9.7A
12 PortType HUB-75D/B



Screen Parameters

No Item Parameter
1 Standard Cabinet Size 500mm*500mm*75mm/1000x1000x75mm
2 Cabinet Weight 5.5KG/13.75KGS
3 Brightness/Adjustment ≥4600cd/m², Level 16- Automatic / Level 100-Manual operation
4 View Angle ≥120°(Vertical),≥120°(Horizontal)
5 Best View Distance 5-15m
6 Grey Scale Within 65536 Step
7 Frame Frequency ≥60Hz
8 Refresh Rate ≥720Hz
9 Signal Input Source Composite, S-video, Component, VGA, DVI, HDMI, SDI, HD-SDI
10 Scan Mode 1/13Scan
11 Drive IC 2038s
12 Module Qty / M2 16
13 Display Color Qty 16777216
14 Continuous Working Time >24(Hrs)
15 Screen Lifespan >100,000(Hrs)
16 MTBF >5000(Hrs)
17 Max. power consumption 800W/m2
18 Ave. power consumption 240W/m2
19 Out of control pixel rate ≥3/10,000(discrete distribution)
20 Control Distance 100M(Ethernet) 500M(Multi-fiber) 10KM(Sigle-fiber)
21 Flatness Screen Surface≤0.5mm,Pixel Pitch≤0.3mm
22 Operation Temperature -10ºC~+50ºC
23 Working Humidity 10%~98%RH
24 Storage Temperature -40ºC~+85ºC
25 Software Connection Standard Computer Connection,Compatiable WithWindows,Unix,Novell
26 protection system Over temperature/overload/power/image compensation/nonlinear correction
27 Working Valtage 200~240 V
28 Dielectric Strength 50HZ/1500V(AC RMS)/1min
29 Temperature Rise Metal≤40K,Insulation≤65K , After Heat Balance
30 IP Grade IP65
31 Computer display mode 1024*768
33 Media Player LED Professional Media Player

Indoor P4.81 Full Color Rental LED Display With Die-casting Aluminum Cabinet 500x1000mm
Product Advantages:
High refresh rate: With NOVA control system,no scanning line when photographed.
High gray level: 256 RGB each, display 16.7M colors, vivid and perfect video effect.
High resolution: The most apparent features of the new generation of LED display.
Good color uniformity:With brand Lamp Nationstar and high refresh 2038s IC.
High Quality: CE, RoHs, FCC, UL, IP65, ISO9001 passed + 96 Hours serious testing time.
Long life span: over100,000hours, warranty at least 2 years.
You need = We design: Provide Personal- Customized led offer.
Price Advantage:
We have the best competitive price at the market, also have the same even better quality
Quality advantage:
From material to finished product, from design to produce, we control all steps,that's the guarantee of the quality and reliability
Service advantage:
Better service at same situation, better cooperation at same service.
Performance Advantage:
Best equality, high consistency, big viewing angle, can repair each led lamps;
Die Casting Aluminum Cabinet
Application Range:indoor or outdoor rental business, support hanging
Structure:with back door,cooling fan,small position guiding pillar,side locks,
and hanging design,precision die-casting cabinet suit for fix installation and rental projects,
light weighted, fast assemble and easy maintenance,most use in rental business.
Indoor P4.81 Full Color Rental LED Display With Die-casting Aluminum Cabinet 500x1000mm
