0-10V LED Driver Power Supply LED Module Components 50000 hours Lifespan
0-10V LED Driver Power Supply LED Module Components 50000 hours Lifespan
Specifications
Brand Name :
Relight
Model Number :
RL-12U-48-EA
Certification :
UL cUL FCC Class 2 RoHS
Place of Origin :
Shenzhen,China
MOQ :
100pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
10000pcs/month
Delivery Time :
About 10 business days
Model :
RL-100U-40-MT-A
Input Voltage :
100-277V
Output Power :
69.3W-100.8W
Output Voltage :
25-42V dc
Output Current :
650mA-2400mA
Dimmable :
0-10V dimming
Warranty :
5 years
Description

0-10V Dimming LED 100W Driver

Quick details:

Model Number RL-100U-40-MT-A
Input Voltage 100-277Vac
Output Power Min: 69.3W Max: 100.8W
Output Voltage 25-42V dc
Output Current 1650mA-2400mA , can output current in 20mA increments
Efficiency 88%
PF >0.9
Current Accuracy 5%
THD <20%
Dimention 240*43.2*30.2 mm
Certification UL cUL FCC Class 2 RoHS
Material Metal Box
Dimmable Function 0-10V dimming
Flicker-free Yes
Protection

Over-Voltage Protection

Over-Current Protection

Short-Circuit Protection
Enviromental Condition

Operating Condition: -25℃~40℃/10%RH~80%RH

Storage Condition: -40℃~85℃/5%RH~90%RH

Ta: 50°C/Tc: 90°C


Features:

- Universal 100-277Vac Input

- Constant Current

- Isolated solution for class I luminaires

- IP20

- 0-10V Dimming

- Flicker-free

- Metal housing

- UL Recognized Certification

- Short circuit protection

- Over current protection

- Over voltage protection

- Revoked self-recovery

- 50,000 hours lifespan design

- 5 Years Warranty

Application:

0-10V LED Driver Power Supply LED Module Components 50000 hours Lifespan

Supple mentary explanation:

1.All performance parameters are the typical value in the case of temperature 25 ℃, 100% load measurement, unless otherwise specified.

2. LED driver is a component of whole lamp in conjunction with the use of terminal equipment, EMC performance due to the impact of LED lighting and wiring, terminal equipment manufacturers need to re-confirm the entire device EMC

Protection:

  • Short Circuit Protection, Auto-Recovery

  • Open Circuit Protection

  • Over Load Protection

  • Overcharge Protection

  • Over Discharge Protection

  • Over Temperature Protection

Remark:

1. Don't connect the terminal of Emergency Equipment and AC power before complete installation, in order to prevent electric shock . 2. Don't dismounting without permission of WeledPower 3. Before monthly maintenance, do cut off the AC power, and unplug the terminal of Emergency Equipment 4. The Emergency Equipment and AC power suppply,must be in the same branch of circuit. 5. Indoor only, applicable to 0-50℃ dry location, don't used in outdoor or damp location. 6. Keep away from flammable gas and heat source.


Our Service:

  • We will reply for you within 24hours once we get your inquiry.
  • Design and produce as your requirement.
  • We can offer you unique design and some our current models.
  • 100%testing guarrantees stable quality, ISO 9001:2000 ,UL, CE&RoHS certification.

Why us Relight?

High Quality
Our CE/RoHS standards insure quality assemblies from start to finish.
Whether it's a simple custom product or a complex turnkey production run,
Relight will adhere to the highest quality standards.
--------------------------------------------------------------------------------
Super Capable
Relight offers the latest in assembly capabilities and qualifications insuring that
quality is built into every product we produce.
------------------------------------------------------------------------------
Many years' Experience
When it comes to your build you want a partner you can depend on.
Our management team has over 8 years of combined industry knowledge. O
ur engineering team has over 10years experience.
--------------------------------------------------------------------------------
Customer First
Protecting your Intellectual Property is job one! Our staff of trained professionals
are all working under a strict confidentiality contract and treat your important
documentation as they would their own.
----------------------------------------------------------------------------
Professional Engineer
We pride ourselves on our ability to custom tailor programs around our customers' needs.
