High CRI 90ra DOB Module 40 * 36mm AC LED Module 5W for downlight / track light
High CRI 90ra DOB Module 40 * 36mm AC LED Module 5W for downlight / track light
High CRI 90ra DOB Module 40 * 36mm AC LED Module 5W for downlight / track light
High CRI 90ra DOB Module 40 * 36mm AC LED Module 5W for downlight / track light
Specifications
Brand Name :
RELIGHT
Model Number :
RL-TOD4036A0005HV
Certification :
CE RoHS
Place of Origin :
CHINA
MOQ :
1pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
negotiation
Delivery Time :
10-12 working day
Packaging Details :
Packed in standard anti-static materials or Customized packing design is available
PCB Materials :
ALUMINUM
CRI :
90ra
Lumen :
400-500lm
Size :
40*36mm
THDI :
<15%
Wattage :
5W
Input voltage :
230Vac
Surge protection :
2.5KV
Description

High CRI 90ra DOB Module 40 * 36mm AC LED Module 5W for downlight / track light


Quick details:

* Power: 5W
* Flux: 400-500lm
* SDCM:<5
* PF:>0.9
* CCT:2700K/3000K/4000K
*CRI: 90ra
* PCB Size: 40*36mm
* MaterialsAluminum



Features:

* AC 230V input directly

* EMI compliance
* THDI: <15%
* Surge protection: 2.5KV
* High-pot level: 1.5KV
* CRI: 80/90 options
* Various CCT available


Standard DOB Module series:

P/NSizeInput (Vac)PFPower(W)Flux(Lm)

CRI

RL-TOD4036A0005HV40*362300.955400-50080/90
RL-TOD4036A0010HV40*362300.9510900-100080/90
RL-TOD4257A0020HV42*572300.95201800-200080/90
RL-TOD4257A0020HV42*572300.95302400-270080/90



Product Images:

High CRI 90ra DOB Module 40 * 36mm AC LED Module 5W for downlight / track light


Dimension:

High CRI 90ra DOB Module 40 * 36mm AC LED Module 5W for downlight / track light

Application:
* DownLight
* Ceiling Light
* Track light
* Wall Light
* Lowbay

High CRI 90ra DOB Module 40 * 36mm AC LED Module 5W for downlight / track lightHigh CRI 90ra DOB Module 40 * 36mm AC LED Module 5W for downlight / track lightHigh CRI 90ra DOB Module 40 * 36mm AC LED Module 5W for downlight / track light

Why us Relight?

* High Quality
Our CE/RoHS standards insure quality assemblies from start to finish. Whether it's a simple custom product or a complex turnkey production run,
Relight will adhere to the highest quality standards.

* Super Capable
Relight offers the latest in assembly capabilities and qualifications insuring that quality is built into every product we produce.
* Many years' Experience
When it comes to your build you want a partner you can depend on.
Our management team has over 8 years of combined industry knowledge. Our engineering team has over 10years experience.

* Customer First
Protecting your Intellectual Property is job one! Our staff of trained professionals are all working under a strict confidentiality contract and treat your important documentation as they would their own.
* Professional Engineer
We pride ourselves on our ability to custom tailor programs around our customers' needs.



RELIGHT Warmly welcome your enquiry here!

COCO Wei
Shenzhen Relight Technology Co.,Ltd
Whatsapp/Mobile: 86-139 2651 8221
Email: sales2@relight-tech.com
