Aluminum 16W D100mm Round LED AC Module for Downlight / Panel Lights 1760Lm, 110Lm/W
Aluminum 16W D100mm Round LED AC Module for Downlight / Panel Lights 1760Lm, 110Lm/W
Specifications
Brand Name :
Relight
Certification :
CE & RoHS
Place of Origin :
Shenzhen,China
MOQ :
100pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
Negotiation
Delivery Time :
About 10 business days
Packaging Details :
Customized packing design or standard antistatic package in carton
Product name :
LED round HV module
Material :
Aluminum
Size :
D100mm
Power :
16W
Input Voltage :
120V / 230V
Current :
360 mA
CCT :
2700K-6500K
CRI :
80-95
Efficiency :
100-150Lm/W
Flux :
1760Lm
PF :
0.95
Dimming :
TRIAC/0-10V
Description

High Lumen LED Module Light LED Retrofit for Ceiling Lights

P/N Size Input Power PF Flux Efficiency CCT CRI Dimming
mm Vac W - Lm Lm/W K - -
RL-HMD100A2802H016-840N Ø100 230 16 0.95 1760 110 4000 80 -
RL-HMD100A2802H016-840T Ø100 230 16 0.95 1760 110 4000 80 TRIAC
RL-HMD100A2802H016-840A Ø100 230 16 0.95 1760 110 4000 80 0-10V
RL-LMD100A1404H016-840T Ø100 120 16 0.95 1760 110 4000 80 TRIAC
RL-LMD100A1404H016-840A Ø100 120 16 0.95 1760 110 4000 80 0-10V
RL-HMD070A2801H009-840N Ø70 230 9 0.95 990 110 4000 80 -
RL-HMD070A2801H016-840T Ø70 230 16 0.95 1600 100 4000 80 TRIAC
RL-HMD070A2801H016-840A Ø70 230 16 0.95 1600 100 4000 80 0-10V
RL-LMD070A1402H016-840T Ø70 120 16 0.95 1600 100 4000 80 TRIAC
RL-LMD070A1402H016-840A Ø70 120 16 0.95 1600 100 4000 80 0-10V

Download:HV Light Engine Datasheet - Round Series.pdf

QC Procedure:

Aluminum 16W D100mm Round LED AC Module for Downlight / Panel Lights 1760Lm, 110Lm/W

LED Retrofit Show:

Aluminum 16W D100mm Round LED AC Module for Downlight / Panel Lights 1760Lm, 110Lm/W

LED retrofit Application:

1. Ceiling lights

2. Advertisement light-box

3. Commercial luminaires

4. Channel lights

5. Troffer lamps
6. Architectural lighting
7. Decorative lighting

8. Panel lights

9. Down lights

10. Highbay/lowbay / flood/ceiling lights

Aluminum 16W D100mm Round LED AC Module for Downlight / Panel Lights 1760Lm, 110Lm/W

Competitive Advantage:

  • Customized design

  • LED component analyze, engineering file service

  • Ultra samples preparation

  • After-sales service

Our Service:

  • We will reply for you within 24hours once we get your inquiry.
  • Design and produce almost any LED pcb as your requirement.
  • We can offer you unique design and some our current models.
  • 100%testing guarrantees stable quality, ISO 9001:2000 ,UL, CE&RoHS certification.

Quotation Requirement :

  • led pcb's size;
  • led pcb's model;
  • led lights' quantity;
  • led pcb's quantity.

Why us Relight?

High Quality

Our CE/RoHS standards insure quality assemblies from start to finish.

Whether it's a simple custom product or a complex turnkey production run,

Relight will adhere to the highest quality standards.

--------------------------------------------------------------------------------

Super Capable

Relight offers the latest in assembly capabilities and qualifications insuring that

quality is built into every product we produce.

------------------------------------------------------------------------------

Many years' Experience

When it comes to your build you want a partner you can depend on.

Our management team has over 8 years of combined industry knowledge. O

ur engineering team has over 10years experience.

--------------------------------------------------------------------------------

Customer First

Protecting your Intellectual Property is job one! Our staff of trained professionals

are all working under a strict confidentiality contract and treat your important

documentation as they would their own.

----------------------------------------------------------------------------

Professional Engineer

We pride ourselves on our ability to custom tailor programs around our customers' needs.
