40W Outdoor 300mA 5000K LED Street Light Module IP65 Beam Angle Adjustable
40W Outdoor 300mA 5000K LED Street Light Module IP65 Beam Angle Adjustable
40W Outdoor 300mA 5000K LED Street Light Module IP65 Beam Angle Adjustable
40W Outdoor 300mA 5000K LED Street Light Module IP65 Beam Angle Adjustable
Specifications
Brand Name :
Relight
Model Number :
RL-LD40H
Certification :
CE,ROHS
Place of Origin :
China
MOQ :
100pcs
Payment Terms :
L/C, T/T, Western Union, MoneyGram,paypal
Supply Ability :
100000pcs/month
Delivery Time :
10 workdays
Packaging Details :
poly bubble and carton
Name :
LED street light
Size :
240*55*1.5mm
leds :
48pcs 3030
CCT :
5000K
IP Grade :
65
Voltage :
240V
Power :
40W
Current :
300mA
Description

40W Outdoor 300mA 5000K LED Street Light Module IP65 Beam Angle Adjustable

40W LED Outdoor Street Light with 300mA 5000K High Quality IP65 Beam Angle Adjustable CE CCC Certification

Specifications

1.Lamp Body: Die-Casting Aluminum. Corrosion Resistant

2.Application with Polyester Substance in its Surface.
3.Implement of Reflect: Made of High Purity Aluminum.

4.Cover: High Strength and High Transparent Toughened Glass
5.Fastener Bolt and Screws: Stainless Steel
6.Arm Diameter: 48 - 60mm

Datasheet

Specifications
Model RL-LD40H
LED Brand Cree, Samsung,Sanan
Norminal Wattage 40W
Input Voltage 100-240/277VAC/DC24V
Power Efficiency >90%
Power Factor >0.95
Lamp Rated Luminous Efficiency >110lm/w
Lamp Rated Lumen output 11000 lm (Lumen tolerance +/- 5%)
Color Rendering Index Ra>70
Color Temperature 3000K or 4000K or 5000K or 5700K
Photometric Type Type I Medium;Type II Medium;Type III Medium,TypeV,Short
Optimal Operating Temperature 25°
Storage Temperatures -40°C~50°C
Working Environment Between-40°C~+50°C, 10%~90%RH
Total Harmonic Distortion < 10%
Lumen Maintenance > 100000 hours -L70, @25 ºC (77 ºF)
Wind Index Force 12
Body and Shell Materials Anodized Aluminum
IP Rating IP66 with test report
IK Rating IK10 with test report
Certification CE,ROHS,CCC
Optional Function 1-10V DC or PWM Signal or Resistance Dimming
Timer/Photocell Control
Warranty 5 years
Packing Details
Fixture Dimension 240*55*1.5mm

Competitive Advantage:

1. With 7 patents of LED street light in China
2. LED module with unique hollow design with optimized dust accumulation
3. Superior secondary optical design
4. Utilizing World’s leading Meanwell Brand LED driver
5. Heat dissipation components are the third generation module of ZGSM
6. Utilizing original LUMILEDS high power LED emitters
7. Suppert horizontal and vertical installation, and the elevation angle is adjustable: Horizontal angle adjustment 0°;10°;15°Vertical angle adjustment 0°;5°;15°
8. Light control/Time control, PWM/Resistance/1-10V dimmable

Light Distribution
40W Outdoor 300mA 5000K LED Street Light Module IP65 Beam Angle Adjustable

Application:

40W Outdoor 300mA 5000K LED Street Light Module IP65 Beam Angle Adjustable

40W Outdoor 300mA 5000K LED Street Light Module IP65 Beam Angle Adjustable

40W Outdoor 300mA 5000K LED Street Light Module IP65 Beam Angle Adjustable

40W Outdoor 300mA 5000K LED Street Light Module IP65 Beam Angle Adjustable

Our Services

We can answer questions on line.If you have questions ,you can ask us directly.

We can design products as customers' demand or manufacture for you if you have pictures or drawing.

1.Your inquiry related to our products or prices will be replied in 24hrs.

2.Well-trained and experienced staffs to answer all your enquires .

3.OEM&ODM, any your customized lightings we can help you to design and put into product.

4.Distributoership are offered for your unique design and some our current models.

5.Protection of your sales area, ideas of design and all your private information.
