Surface Mount Common Mode Choke MOX-CMCS-0805E Applied Cable Modems
Surface Mount Common Mode Choke MOX-CMCS-0805E Applied Cable Modems
Specifications
Brand Name :
Shareway
Model Number :
MOX-CMCS-0805E
Certification :
CE UL RoHS ISO9001:2008
Place of Origin :
Guangdong China
MOQ :
100/500/1000
Price :
Supportive
Payment Terms :
TT,Paypal
Supply Ability :
3000K.PCS/Month
Delivery Time :
Stock or 3 weeks
Packaging Details :
2000pcs/Reel
Product name :
Surface Mount Common Mode Choke MOX-CMCS-0805E used in cable modems
Usage :
Digital cameras
Type :
wire wound Choke
Feature :
Excellent solderability
Size :
2.0*1.2*1.0mm
Rated CurrentRated Current :
330.0 mA
Description

Surface Mount Common Mode Choke MOX-CMCS-0805E used in cable modems

Description:

  • Surface mount common mode choke
  • SMD chip inductor
  • Size: 2.0*1.2*1.0mm
  • With RoHS certification

Application:

cable modems, notebooks, LCD televisions and digital cameras. The

wire wound design provides a low DC resistance and high current tolerance.

Similar Product:

Part Number Common Mode
Impedance ¹
@ 100 MHz (Ω)		 Rated
Voltage
V (DC)		 Withstanding
Voltage
V (DC)		 Rated
Current²
(mA) Max.		 DC
Resistance
(Ω) Max.		 Insulation
Resistance
(mΩ) Max.
MOX-CMCS-0805E-670S 67.0 50.0 125.0 330.0 0.35 10.0
MOX-CMCS-0805E-900S 90.0 50.0 125.0 300.0 0.40 10.0
MOX-CMCS-0805E-121S 120.0 50.0 125.0 280.0 0.45 10.0
MOX-CMCS-0805E-181S 180.0 50.0 125.0 250.0 0.50 10.0

Surface Mount Common Mode Choke MOX-CMCS-0805E used in cable modems

Shape and Dimensions:

Surface Mount Common Mode Choke MOX-CMCS-0805E Applied Cable Modems

L (LENGTH) : 2.00 ± 0.10

W (WIDTH) : 1.20 ± 0.10

H (THICKNESS) : 1.00 ± 0.10

S (TERMINAL) : 0.45 ± 0.10

T (TERMINAL) : 0.45 ± 0.10
