T1212 Dual Surface Mount Transformer Modules 17.15*15.24*8.64mm 100Base-T Speed
T1212 Dual Surface Mount Transformer Modules 17.15*15.24*8.64mm 100Base-T Speed
T1212 Dual Surface Mount Transformer Modules 17.15*15.24*8.64mm 100Base-T Speed
T1212 Dual Surface Mount Transformer Modules 17.15*15.24*8.64mm 100Base-T Speed
Specifications
Brand Name :
Shareway
Model Number :
T1212
Certification :
CE UL RoHS ISO9001:2008
Place of Origin :
Guangdong China
MOQ :
100/500/1000
Price :
Supportive
Payment Terms :
TT,Paypal
Supply Ability :
3000K.PCS/Month
Delivery Time :
Stock or 3 weeks
Packaging Details :
Reel ,Tube
Product name :
T1212 Dual Surface Mount Transformer Modules Ethernet Magnetic Transformers
Mounting :
Surface mount
Type :
Dual Surface Mount Transformer Modules
Application :
Router
Max Size :
17.15mm*15.24mm*8.64mm
Speed :
100Base-T
Description

T1212 Dual Surface Mount Transformer Modules Ethernet Magnetic Transformers

Description:

T1/E1/CEPT/ISDN-PRI INTERFACE MODULES Dual Surface Mount Transformer Modules,1500 Vrms, Extended Temperature Range.

Feature:

  • RoHS peak reflow temperature rating 245°C
  • Optimized for enhanced EMC performance
  • Extended temperature range
  • Dual SMT package contains transformers with common mode chokes on both transmit and receive channels
  • Models matched to leading transceiver ICs
  • Patented Interlock Base construction for high reliabilit
  • UL1950 approved

Electrical Specifications @ 25°C
RoHS
Compliant
Part Number		 Turns Ratio 2
(Pri:Sec ± 2%)		 Secondary
OCL @ 25°C
(mH MIN)		 LL
(μH MAX)		 CW/W
(pF MAX)		 DCR Pri
(Ω MAX)		 Primary Pins
EXTENDED TEMPERATURE RANGE MODELS 1 – OPERATING TEMPERATURE -40°C TO +85°C
T1212NL 1CT:1CT & 1CT:2CT 1.20 .60 35 .90 1-3, 4-6
T1215NL 1CT:1.41CT & 1CT:1.41CT 1.20 .60 30 .70 1-3, 4-6
T1217NL 1CT:2.42CT & 1CT:2.42CT 1.20 .60 25 .60 1-3, 4-6
T1219NL 1CT:2.42CT & 1CT:2.42CT 1.20 .60 35 .90 1-3, 4-6

1. Extended Temperature Range Models — For extended temperature range transformers (-40°C to

+85°C operating temperature range), OCL (Open Circuit Inductance) is specified at both -40°C

and +25°C. At -40°C, OCL is 600 μH minimum. All other parameters are specified at +25°C only.

Standard temperature range is 0°C to +70°C.
2. Turns ratio is specified primary:secondary (CT = Center Tap).
3. Standard packaging for the surface mount package is anti-static tubes.

T1212 Dual Surface Mount Transformer Modules Ethernet Magnetic Transformers

Shape and Dimensions:

T1212 Dual Surface Mount Transformer Modules 17.15*15.24*8.64mm 100Base-T Speed

Product Picture:

T1212 Dual Surface Mount Transformer Modules 17.15*15.24*8.64mm 100Base-T Speed

T1212 Dual Surface Mount Transformer Modules Ethernet Magnetic Transformers

HOW TO ORDER
1. Please send me your datasheet or part number you need.
2. We will offer the replacement quotation for your reference
3. The free samples are available for your approval.
4. After sample testing, we will step into the mass order.
5. The Proforma Invoice will send for your confirmation
6. After the goods finished, we send the goods to you and tell you the tracking number.
7. We will track your goods until you receive the goods.
Remarks:
1. Sample orders are avaliable.
2. Price is negotiable for orders of large quantity.
3. Customized orders (OEM/ODM orders) are avaliable.
4. Contact us for available flavors list. International Certifications:
1. ISO9001:2008
2. UL
3. Reach
4. RoHs
Our service:
1. 100% tested before shipping
2. Have alternative for Halo, Pluse, , We-online, Chilisin, Coilcraft......Same quality but better price
3. Free sample available
4. Provide new design for customer
