SMD Ethernet Magnetic Transformers , 23Z356SMFNL Discrete Telecom Isolation Transformer
SMD Ethernet Magnetic Transformers , 23Z356SMFNL Discrete Telecom Isolation Transformer
SMD Ethernet Magnetic Transformers , 23Z356SMFNL Discrete Telecom Isolation Transformer
SMD Ethernet Magnetic Transformers , 23Z356SMFNL Discrete Telecom Isolation Transformer
Specifications
Brand Name :
Shareway
Model Number :
23Z356SMFNL
Certification :
CE UL RoHS
Place of Origin :
Guangdong China
MOQ :
100/500/1000
Price :
Supportive
Payment Terms :
TT,Paypal
Supply Ability :
1000K.PCS/Month
Delivery Time :
Stock or 3 weeks
Packaging Details :
Reel ,Tube
Product name :
23Z356SMFNL SMD Ethernet Magnetic Transformers Discrete Magnetic Transformer
Transformer Type :
10/100Base-T
Mounting Type :
SMD/SMT
Size / Dimension :
11.5mm*9.53mm
Turns Ratio :
1 : 1 Transmitter, 1 : 1 Receiver
Category :
Datacom/Telecom Transformer
Sample :
4pcs free samples
Description

23Z356SMFNL SMD Ethernet Magnetic Transformers Discrete Magnetic Transformer

PRODUCT DETAILS:

  • ROHS COMPLIANT.
  • HEADER :PHENOLIC WITH FLAMMABILITY RATING UL 94V-O OR BETTER.
  • STORAGE TEMPERATURE :-20 ℃ TO +125 ℃
  • COMPLIANCE TO J-STD

A. J-STD-002: SOLDERABILITY AT 245℃ REFLOW PROFILE

B. J-STD-020: LEVEL 1, NO MOISTURE SENSITIVE

C. J-STD-075: R7, 245℃ MAXIMUM THROUGH REFLOW SOLDER

ELECTRICAL CHARACTERISTICS AT +25℃ UNLESS OTHER SPECIFIED

PARAMETER SPECIFICATIONS
OPERATING TEMPERATURE 0℃ TO +70℃
POLARITY PER SCHEMATIC
TURNS RATIO

( 1-3 ):( 16-14 )=1CT:1CT±5%

( 6-8 ):( 11-9 )=1CT:1.41CT±5%
INDUCTANCE(OCL)

( 1-3 ) = 160 uH MIN

( 6-8 ) = 160 uH MIN. (AT 10 KHz 20 mVRMS)

(16-14 )- 15 =68 uH MIN
COUPLING CAPACITANCE 12 pF MAX ( AT 100KHz , 20 mVRMS )

IMPEDENCE

( 9-11 ) -10

 10-20 MHz 30 MHz 70-100 MHz
700 OHM MIN 600 OHM MIN 200 OHM MIN
SRF ( 9-11 )-10 = 7.5 MHz MIN

INPUT - OUTPUT

ISOLATION

 1500 VRMS FOR 60 SECONDS

23Z356SMFNL SMD Ethernet Magnetic Transformers Discrete Magnetic Transformer

SMD Ethernet Magnetic Transformers , 23Z356SMFNL Discrete Telecom Isolation Transformer

PRODUCT PICTURE
