1CT:1.33CT DC DC Converter Isolation Transformer 500uH 3k Vrms For MAX3535E TGMR-340NA5RL
1CT:1.33CT DC DC Converter Isolation Transformer 500uH 3k Vrms For MAX3535E TGMR-340NA5RL
Specifications
Brand Name :
Shareway
Model Number :
TGMR-340NA5RL
Certification :
RoHS,Reach,ISO9001-2001
Place of Origin :
Guangdong,shenzhen
MOQ :
500/1000
Price :
Negotiation
Payment Terms :
TT,Paypal,West Union
Supply Ability :
100k pcs/month
Delivery Time :
Stock Or 3 weeks
Packaging Details :
Tape& Reel / Tray / Bulk
Product name :
500uH, 3k Vrms 1CT:1.33CT DC / DC Converter Isolation trafo For MAX3535E TGMR-340NA5RL
Number of Lines :
2
Inductance :
500 uH
Current Rating :
150 mA to 300mA
Operating Temperature :
-40°C ~ 85°C
Mounting Type :
Surface Mount
Core :
Ferrite
Frenquency range :
420kHz
Description

500uH, 3k Vrms 1CT:1.33CT DC / DC Converter Isolation trafo For MAX3535E TGMR-340NA5RL


Typical Applications:

  • Isolated H-Bridge DC/DC Converter
  • Drive a 3.3V or 5V power source
  • Designed specifically for use with the MAX253, MAX845, and MAX3535 drivers.

Product details:

Part Number Trader Part Number Circuit Turns Ratio (±3%) Pri: Sec Cw/w pf Max OCL uH Isolation Vrms
SGMR-340 TGMR-340NA5RL 1CT:1.33CT 10 800 3000


Mechanical Dimensions:

1CT:1.33CT DC DC Converter Isolation Transformer 500uH 3k Vrms For MAX3535E TGMR-340NA5RL

Schematics A:

1CT:1.33CT DC DC Converter Isolation Transformer 500uH 3k Vrms For MAX3535E TGMR-340NA5RL

Photos of the TGMR340NA5RL 6 Pin 3KVrms DC / DC Converter Isolation Modules For MAX253,MAX845, and MAX3535


1CT:1.33CT DC DC Converter Isolation Transformer 500uH 3k Vrms For MAX3535E TGMR-340NA5RL

1CT:1.33CT DC DC Converter Isolation Transformer 500uH 3k Vrms For MAX3535E TGMR-340NA5RL

1CT:1.33CT DC DC Converter Isolation Transformer 500uH 3k Vrms For MAX3535E TGMR-340NA5RL

1CT:1.33CT DC DC Converter Isolation Transformer 500uH 3k Vrms For MAX3535E TGMR-340NA5RL
