6 Llayers 6mil Rigid Flex Multilayer PCB Board Immersion Silver
6 Llayers 6mil Rigid Flex Multilayer PCB Board Immersion Silver
6 Llayers 6mil Rigid Flex Multilayer PCB Board Immersion Silver
6 Llayers 6mil Rigid Flex Multilayer PCB Board Immersion Silver
6 Llayers 6mil Rigid Flex Multilayer PCB Board Immersion Silver
6 Llayers 6mil Rigid Flex Multilayer PCB Board Immersion Silver
Specifications
Brand Name :
Leadsintec
Model Number :
PCBA
Certification :
IATF16949, ISO13485, ISO9001
Place of Origin :
Shenzhen
MOQ :
1pcs
Price :
Negotiable (Depends on your gerber and bom)
Payment Terms :
L/C, T/T, D/A, D/P, Western Union
Supply Ability :
80000pcs/month
Delivery Time :
1-30days
Packaging Details :
PCB: Vacuum Packing / PCBA: ESD Packing
Product name :
Multilayer PCB Board
Copper thickness :
1/2OZ 1OZ 2OZ 3OZ
Base material :
FR-4
Surface finishing :
HASL/OSP/ENIG
Solder mask color :
White Black Yellow Green Red
Layers :
1-58 layers
Type :
pcb printed circuit board
Pcb standard :
IPC-II Standard,IPC-A-610 E Class II-III
Description

6 Llayers 6mil Rigid Flex Multilayer PCB Board Immersion Silver​

MultilayerPcb Board Shenzhen Circuit Board OEM PCB PCBA Manufacturer Customized Circuit Board

Rigid-Flex Circuits and Assemblies


Ideal for hand-held to large devices, Rigid-Flex Circuits, and Assemblies combine the benefits of flexible copper circuitry and rigid PCB circuitry into a unitized power and signal solution for superior reliability, system cost savings, and optimized packaging.

Leadsintec has spent years refining our engineering support, equipment, and technology to better our rigid-flex PCB boards. We have well-experienced technicians knowledgeable in state-of-the-art technology to build your rigid-flex PCBs to customers' exact specifications.

Rigid-Flex PCB Manufacturing Capability

Items Type Normal Manufacturing Capability
Standard Inspection Std. IPC-6013 Class 2, IPC-A-600G Class 2, IPC-6013 Class 3
Test Std. IPC-TM-650,GB/T4677-2002
Material DuPont AL9111R, AP9121R, AP9131R, AP8525R
Panasonic R-F775 11RB-M, R-F775 22RB-M, R-F775 21RB-M
Taiflex NDIR050513HJY,IDIR051013HJY,NDIR100520HJY,THKD200520
No Flow PP VT-47N,VT-901
CCL ITEQ IT180A , ShengYi 1000-2,N4000-13, Rogers4350B,4003C
Process capacity Layers 2-20
Thickness 8-118mil
Max dimension 15.74X28 Inch
Min precision Of Dim ±4mil
Min diameter of holes 4mil (Laser drill); 6mil(mechanical drill)
Aspect ratio 16:1

Min trace width/space

wtidth of outer

 3.0/3.0mil

Min trace width/space

wtidth of outer

 3.5/3.5mil
wtidth of outer layer(2OZ finished 5/5mil

Min trace width/space

wtidth of inner

 3.5/3.5mil

Min trace width/space

wtidth of out layer(1OZ

 4/4mil
Min trace width/space wtidth of gridding circr 5/5mil

Min trace width/space

wtidth of out layer(2OZ finishedcopper,Flex layer on top or bottom)

5/5mil(1/3,1/2oz copper)；6.5/5mil(1oz copper)；8/5.5mil

(2oz copper)；

Min distance Between

drilling&conductor(via holes)

 7mil(2layers);9mil(3~6Llayers);11mil(≥7layers)

Min distance Between

drilling&conductor(com ponent holes)

 10mil(2layers);12mil(3~6Llayers);14mil(≥7layers)

Min distance Between

drilling&conductor(burie d &blind holes)

 7mil

Min ring of inner

layer(via holes)

 5mil(≤6 Layers) ；8mil(＞8Layers)
Min ring of inner layer(component holes) 8mil(≤6Layers) ；11mil(＞8 Layers)
coalescent location of rigid and flex 1mm
HDI board 1+n+1
Surface treatment Plating Gold(Hard gold) Normal:0.25-0.76um;Hard gold:0.76-2um；
ENIG Ni:3--8um,Au:0.05-0.1um
Immersion Tin 0.80-1.20um
Immersion Silver 0.10-0.30um
0SP 0.15-0.30um
HASL 2-40um
HASL lead free 2-40um
Silver ink 10-25um
Selective surface finishing

ENIG+GOLD Finger; ENIG+HASL; ENIG+OSP; Soft gold+

GOLD Finger; Flash gold+HASL; immersion Tin+gold finger; Immersion sliver+gold finger; OSP +gold finger; Silver ink+Plating gold; Silver ink+ENIG.
Routing Outline Tol. +/-4mil

6 Llayers 6mil Rigid Flex Multilayer PCB Board Immersion Silver

Quality Rigid-Flex Circuits

At Rigid-Flex Circuits Manufacturing, Leadsintec specialize in bringing advanced rigid flex circuit designs to market, and we consistently build on over 20 years of manufacturing expertise. ISO9001, ISO13485, IATF16949 Certification. Our facilities offer world-class, cost-effective PCB production and PCB Assembly. For more information about what we can do for your PCB or PCBA project, get in touch with our team today.

6 Llayers 6mil Rigid Flex Multilayer PCB Board Immersion Silver

<p font-size:14px;font-style:normal;font-variant-ligatures:normal;font-variant-caps:normal;font-weight:400;letter-spacing:normal;orphans:2;text-align:start;text-indent:0px;text-transform:none;white-space:normal;widows:2;word-spacing:0px;-webkit-text-stroke-width:0px;text-decoration-style:initial;text-decoration-color:initial;"="" style="padding: 0px; word-spacing: -1.5px; font-family: Arial; text-align: center;">

Rigid Flex PCB Application Areas:


The characteristics of Rigid-flex PCB determine that its application areas cover all application areas of FPC in PCB, such as:
mobile phone
Button board and side buttons, etc.
Computer and LCD screen
Motherboard and display screen, etc.
CD Walkman
Disk Drive
NOTEBOOK.
Latest use
Hard disk drive (HDD, hard disk drive) suspension circuit (Su ensi.N circuit) and xe package board, and other components.
