Double Sided Industrial PCB Assembly 6mm Halogen Free IATF 16949 Approved
Double Sided Industrial PCB Assembly 6mm Halogen Free IATF 16949 Approved
Double Sided Industrial PCB Assembly 6mm Halogen Free IATF 16949 Approved
Double Sided Industrial PCB Assembly 6mm Halogen Free IATF 16949 Approved
Double Sided Industrial PCB Assembly 6mm Halogen Free IATF 16949 Approved
Double Sided Industrial PCB Assembly 6mm Halogen Free IATF 16949 Approved
Specifications
Brand Name :
Leadsintec
Model Number :
PCBA
Certification :
IATF16949, ISO13485, ISO9001
Place of Origin :
Shenzhen
MOQ :
1pcs
Price :
Negotiable (Depends on your gerber and bom)
Payment Terms :
L/C, T/T, D/A, D/P, Western Union
Supply Ability :
80000pcs/month
Delivery Time :
1-30days
Packaging Details :
PCB: Vacuum Packing / PCBA: ESD Packing
Product name :
Electronics PCBA Service
Copper thickness :
1/2OZ 1OZ 2OZ 3OZ
Surface finishing :
HASL/OSP/ENIG
thick :
6mm
Layers :
1-58layers
Base material :
FR-4,CEM-3,teflon,TACONIC,CM-1 CM-3 FR-1 FR-4 AL-PCB
Description

Double Sided Industrial PCB Assembly Halogen Free IATF16949 Electronics PCBA Service

PCBA Technical Capacity

SMT

Position accuracy:20 um

Components size:0.4×0.2mm(01005) —130×79mm,Flip-CHIP,QFP,BGA,POP

Max. component height::25mm

Max. component height::25mm

Max. PCB size:680×500mm

Min. PCB size: no limited

PCB thickness:0.3 to 6mm

Wave-Solder

Max. PCB width:450mm

Min. PCB width: no limited

Component height:Top 120mm/Bot 15mm

Sweat-Solder

Metal type :part, whole, inlay, sidestep

Metal material:Copper , Aluminum

Surface Finish:plating Au, plating sliver , plating Sn

Air bladder rate:less than20%

Testing

ICT,Probe flying,burn-in,function test,temperature cycling,AXI – 2D and 3D automated X-ray inspection, AOI – automated optical inspection

Details for PCB &PCBA

Base material

FR4,High-TG FR4,CEM3,aluminum, High Frequencey frequency(Rogers,Taconic,Aron,PTFE,F4B)

Layers

1-4 Layers(Alunimum), 1-32 layers(FR4)

Aluminum Machining

Drilling, Tapping, Milling, Routing, Die-Punching,
Break-off tab available

Min SMD Pad Pitch

0.2mm (8mil)

Surface Finishing

HASL lead-free,ENIG, Plated Gold, Immersion Gold,OSP

Solder Mask Color

Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue

Legend Color

Black, White, etc

Assembly Types

Surface mount
Thro-hole
Mixed technology (SMT & Thru-hole)
Single or double-sided placement
Conformal coating
Shield cover assembly for EMI emission control

Component types

SMT 01005 or larger
BGA 0.4mm pitch, POP (Package on Package)
WLCSP 0.35mm pitch
Hard metric connectors
Cable & wire

Stencils

Laser-cut stainless steel

Double Sided Industrial PCB Assembly 6mm Halogen Free IATF 16949 Approved

Double Sided Industrial PCB Assembly 6mm Halogen Free IATF 16949 Approved

FAQ

Q1.What is needed for PCB PCBA quotation?

A: PCB: Quantity, Gerber file, and Technic requirements(material, surface finish treatment, copper thickness, board thickness,...)PCBA: PCB information, BOM, (Testing documents...)

Q2. What file formats do you accept for PCB PCBA production?

A: Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF,word,txt)

Q3. Are my files safe?

A: Your files are held in complete safety and security. We protect the intellectual property of our customers in the whole process. All documents from customers are never shared with any third parties.

Q4. MOQ?

A: There is no MOQ.We are able to handle Small as well as large volume production with flexibility.

Q5.Shipping cost?

A: The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost.
