4 Layers Black Soldmask White Silkscreen Prototype PCB Assembly
4 Layers Black Soldmask White Silkscreen Prototype PCB Assembly
Specifications
Brand Name :
OEM
Model Number :
KAZA-068
Certification :
UL/ROHS/ ISO9001
Place of Origin :
Guangdong , China
MOQ :
1 Unit
Payment Terms :
Western Union, T/T, L/C, D/P, MoneyGram
Supply Ability :
100000 pieces
Delivery Time :
2 - 3 weeks
Packaging Details :
P/P
Product Name :
PCBA
Min. Line Spacing :
3 Mil (0.075 Mm)
Min. Hole Size :
3mil (0.075mm)
Components Purchasing :
OK
Description

4 Layers Black Soldmask White Silkscreen Prototype PCB Assembly manufacturer

1. Features of acquisition module circuit board

1. One Stop OEM Service, Made in Shenzhen of China

2. Manufactured by Gerber File and BOM List from Customer

3. FR4 Material, Meet 94V0 standard

4. SMT, DIP technology suport

5. Lead Free HASL, Environmental Protection

6. UL, CE, ROHS Compliant

7. Shipping By DHL,UPS, TNT, EMS or Customer requirement

2. module circuit board Technical capability

SMT Position accuracy:20 um
Components size:0.4×0.2mm(01005) —130×79mm,Flip-CHIP,QFP,BGA,POP
Max. component height::25mm
Max. PCB size:680×500mm
Min. PCB size:no limited
PCB thickness:0.3 to 6mm
PCB weight:3KG
Wave-Solder Max. PCB width:450mm
Min. PCB width: no limited
Component height:Top 120mm/Bot 15mm
Sweat-Solder Metal type :part, whole, inlay, sidestep
Metal material:Copper , Aluminum
Surface Finish:plating Au, plating sliver , plating Sn
Air bladder rate:less than20%
Press-fit Press range:0-50KN
Max. PCB size:800X600mm
Testing ICT,Probe flying,burn-in,function test,temperature cycling

PCB Assembly(SMT) Product Capacity

SMT Capacity
SMT Item Capacity
PCB Max. size 510mm*1200mm(SMT)
Chip component 0201, 0402, 0603, 0805, 1206 package
Min.pin space of IC 0.1mm
Min. space of BGA 0.1mm
Max.precision of IC assembly ±0.01mm
Assembly capacity ≥8 million piots/day
DIP capacity 6 DIP production lines
Assembly testing Bridge test,AOI test, X-Ray test, ICT(In Circuit Test),FCT(Functional Circuit Test)

FCT(Functional Circuit Test)		 Current test, voltage test, high temperature and low temperature test,Drop Impact Test,aging test,water proof test,leakage-proof test and etc.Different test can be done according to your requirement.

2. PCBA Pictures
