Specifications
Brand Name :
Morel
Model Number :
Morel - R12
Certification :
CE,ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram,Paypal
Supply Ability :
500/month
Delivery Time :
2-3days
Packaging Details :
Normal packaging
part no :
Morel - R12
Warranty :
6 months
Usage :
Morel SMT machine
Quality :
100% Tested
Type :
SMT machine
Product name :
Lead- free Hot Air Reflow Oven - Morel R12
Condition :
Original new
Description
Lead- free Hot Air Reflow Oven - Morel R12
Warranty:6 months
Usage:FUJI SMT machine
Quality:100% Tested
Brand Name:Morel
Type:SMT machine parts
Condition:Original new
Model Morel R12

Heating System

 Number of heating zones Top 12/Bottom 12
Number of cooling zones 2
Heating passage 4600mm
Heating style Hot air
Cooling Style Air Oven: Forced air; Nitrogen Oven: Water Chiller
Exhaust Volume 10m³/min * 2 vanes

Conveyor System

 Max. Width of PCB 450mm
Mesh belt width 500mm
Conveyor Direction L→R(or R→L)
Process Height 900±20mm
Conveyor Style Mesh and chain
Range of rail width 0-450mm
Conveyor speed 0-2000mm/min
Auto/manual Lubrication Standard
Fixed track Front track fixed(option: rear track fixed)
Product clearance Top and bottom 25mm

Control system

 Power supply 5 line 3 phase 380V 50/60Hz
Total consumption 60kw
Startup consumption 58kw
Steady consumption 12KW
Ramp up time About 20 mins
Temp. set point range Room temperature-300℃
Temp. control method PID close loop control & SSR driving
Temp. control precision ±1℃
Temp. deviation on PCB ±2℃
Data storage Process Data and status storage(80GB)
Nozzle plate Aluminum Alloy Plate
Abnormal Alarm Abnormal temp. (overtemp/low temp.)
Board dropped alarm Light tower: Amber-warming, Green-normal, Red-abnormal

General

 Dimension(L*W*H) 6000×1400×1550mm
Weight 2800KG
Color Computer grey

2 Cooling Zones Durable SMT Line Machine Morel R12 Lead Free Hot Air Reflow Oven2 Cooling Zones Durable SMT Line Machine Morel R12 Lead Free Hot Air Reflow Oven2 Cooling Zones Durable SMT Line Machine Morel R12 Lead Free Hot Air Reflow Oven
