Full Pneumatic Steel Mesh Cleaning Machine 400 - 600L/Min Air consumption
Full Pneumatic Steel Mesh Cleaning Machine 400 - 600L/Min Air consumption
Full Pneumatic Steel Mesh Cleaning Machine 400 - 600L/Min Air consumption
Full Pneumatic Steel Mesh Cleaning Machine 400 - 600L/Min Air consumption
Specifications
Brand Name :
GS
Model Number :
RL-750
Place of Origin :
China
MOQ :
1 PCS
Price :
USD+negotiable+pcs
Payment Terms :
T/T
Supply Ability :
1+pcs+per days
Delivery Time :
1-7 days
Packaging Details :
1200*800*2000mm
Applicable steel mesh size :
L750 × W750 × H40(mm) [large size needs to be customized]
Dimensions :
L1000*W700*H1730 (mm)
Liquid tank maximum capacity :
40 liters
Optimal liquid usage :
30 liters
Cleaning method :
360° rotary double-side isobaric jet high pressure jet (cleaning + blow drying)
Cleaning time :
2-5min
Drying time :
2-5min
External air source :
0.4 ~ 0.6 (Mpa)
Air consumption :
400 ~ 600(L/Min)
Exhaust port size :
Φ125×H25(mm)
Filter system (primary) + Primary filter element filtration :
Filter impurities and labels
Filtration system (secondary) + secondary filter element filtration :
Filter solder paste and rosin particles
Filtration system (three-stage) + three-stage filter element filtration :
1 per cent (filter solder paste and rosin particles)
Net weight :
about 210Kg
Description

Product features:
All stainless steel body: beautiful, wear resistance, corrosion resistance, in line with environmental requirements and standards;
Full pneumatic operation, no electricity, no fire and other safety hazards;
Side wall air intake blow-drying design;
Humanized design: one-button operation and automatic filling and draining function, the operation is very simple;
Replaceable modular controller and quick-plug design, maintenance is also very simple and convenient;
Two-stage filtration system, low exhaust and S-shaped exhaust pipe design: solvent recycling, low liquid consumption;
High density isobaric double-sided rotary cleaning nozzle, strong cleaning force, does not destroy the tension of steel mesh.
Systematic integration of global quality control devices to ensure excellent quality, stable performance and long service life;
