Double-sided Telecentric Lens 2D-AOI PCBA Testing Equipment SI-1020 for PCB Thickness Range 0.6-6mm
Double-sided Telecentric Lens 2D-AOI PCBA Testing Equipment SI-1020 for PCB Thickness Range 0.6-6mm
Specifications
Brand Name :
Sailyond
Model Number :
SI-1020
Place of Origin :
China
MOQ :
1 PCS
Price :
USD+negotiable+pcs
Payment Terms :
T/T
Supply Ability :
1+roll+per days
Delivery Time :
1-7 days
Packaging Details :
1100*1500*2200mm
Model :
SI-1020
PCB Transfer Size :
50mm*50mm-510mm*460mm
PCB Inspection Size :
50mm*50mm-510mm*460mm
PCB Thickness Range :
0.6-6mm
Maximum PCB Weight :
10kg
Component Height :
Top 25mm;Bottom 40mm
PCB Transfer Method :
Belt Conveyor
Edge Width :
3mm
Camera Pixel :
26M Industrial Area Color Camera,Cell:2.5um
Recogniton Accuracy :
10um
Light Source Solution :
Four-color Integral Ring Light Source:White+Red Green Bue
Optical Lens :
Double-sided Telecentric Lens,0.256x Magnification
Camera Field of View :
26MP@10um:50mm*50mm
Scanning Speed :
0.3sec/FOV
Component Inspection :
Missing,Wrong,Misplaced,Standing,Polar Reverse
Solder Inspection :
Multi-solder,Less-solder,Connected-solder,False-solder
Component Library :
NA
Special Feature :
One-key Programming
Device Working Mode :
Standard SMEMA Front and Rear Communication Port
Front and Rear Device Docking Helght :
880mm-920mm
Front and Rear Device Communication Protocol :
One-key Programming
Storage Memory :
64G
Description

* Strong generalization, high detection rate, low false alarm rate
* End-to-end cloud connectivity, support for remote management
* Support MES system, support offline operation, support online non-stop debugging.
* 0 missing report, set 40+ cutting-edge A1 model strategy, efficient and accurate detection, false detection rate <1%, reliable AI technology, effectively reduce algorithm misjudgment
* Programming time <1 minute, no component library, to achieve true one-click programming
* 1 millisecond algorithm inference, inference speed is greatly improved, model algorithm is extremely optimized
* Does not rely on the device library, complete the intelligent detection of the device; And can identify the devices not included in CAD(device location information);
* Through efficient learning of the global characteristics of devices and defects, intelligent generation of different devices, different detection areas, different defect types of decision indicators; .
* Normalization of multiple complex thresholds for defect detection into tolerance threshold adjustments without the need to describe and define device details; And through the study of statistical data, the quantitative threshold adjustment suggestions are given.
There is no need for excessive technical requirements for programming personnel, and replacements can be on the job at any time.
