Nitrogen Wave Soldering Machine KTN-450
Nitrogen Wave Soldering Machine KTN-450
Nitrogen Wave Soldering Machine KTN-450
Nitrogen Wave Soldering Machine KTN-450
Nitrogen Wave Soldering Machine KTN-450
Nitrogen Wave Soldering Machine KTN-450
Specifications
Model Number :
KTN-450
Place of Origin :
shenzhen
MOQ :
1
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
1000set/month
Delivery Time :
8days
Packaging Details :
carton
PCB width :
Max.50~350mm by Frame
PCB convey height :
750±50mm
Conveyor speed :
0-1800mm／Min
Angle :
3~7 degree
Description

Nitrogen Wave Soldering Machine KTN-450

Nitrogen Wave Soldering Machine KTN-450

Infrared heating method, by this method, the air won't flow, It can keep high level nitrogen level in soldering part. easy to reach 30-50 PPM. High nitrogen level make the solder clean and very few dross nearly no, and for the PCB surface it's very clean, no dross on the surface, so PCB no need cleaning , no need cleaning machine, save many cost for cleaning. High nitrogen level also make the solder more few empty holes inside the solder.

Machine Specification
Model KTN-450 Solder pot type 4th adjustable
PCB width Max.50~350mm by Frame Heating technology Matrix straight heating, heating efficiency up to 95%
PCB convey height 750±50mm Solder pot temp. Room temp. to 350℃,accuracy±1-2℃
Conveyor speed 0-1800mm／Min Solder pot temp. accuracy ±1℃
Angle 3~7 degree Finger types Strong titanium finger /customized
Component height limit Max.100mm Solder bar adding way Manually
Wave height range 0~18mm keep steady Temp. control P.I.D +SSR
Wave quantity 2 Machine control PLC+PC
Preheating length 1800mm Width adjust Manually/motorized
Preheating zone 4 zones Flux adding way Automatic
Conveyor direction Left to right Flux flow rate 10~100ml/min
Preheat power 10KW Spray method Step motor+ ST-6 nozzle
Preheat temp. Room temp. to 250℃ (adjustable) Flux recycle Tray to collect
Heating model Infrare Tube Electricity 3P 5 wires 380V/3P 220V
Solder bar type Lead-free Total power Max.22kw
Solder pot power 14kw Normal running power Approx.3-5kw
Solder pot capacity Approx.480kg Air supply 4~7KG/CM2
Solder pot material Cast iron Dimension 5500*1600*1730mm
Weight Approx.2500kg

Keywords:
Wave Soldering Machine, Dual Rail Wave Soldering Machine, High End Wave Soldering Machine, Nitrogen Wave Soldering Machine, China Wave Soldering Machine, Wave Soldering Machine Manufacturer.
