YAMAHA KHJ-MC131-00 SSjZS 8MM Feeder SPROCKET ASSY

1 KHJ-MC10C-00 SEAL,MAIN LABEL
2 KHJ-MC131-00 SPROCKET ASSY.
2-1 KHJ-MC131-01 SPROCKET ASSY. 1 Resin
2-2 KHJ-MC131-02 SPROCKET ASSY. 1 Metal
3 KHJ-MC13A-00 SHIM,SPROCKET

5 90990-01J043 BOLT,EXTRA LOW HEAD
5-1 KHJ-MC13E-01 SCREW,SLIM HRAD
6 KHJ-MC141-02 TAPE GUIDE 1
6-1 KHJ-MC141-03 TAPE GUIDE 1 Resin
6-2 KHJ-MC141-04 TAPE GUIDE. 1 Metal
KLJ-MC141-00 TAPE GUIDE 1 STD
KLJ-MC14A-00 TAPE GUIDE,W8P1 1 1mm Pitch
KLJ-MC14B-00 TAPE GUIDE,W8P4 1 4mm Pitch


7 KHJ-MC144-00 LEVER,TAPE GUIDE R
8 KHJ-MC145-00 LEVER,TAPE GUIDE F
8-1 KHJ-MC145-01 LEVER,TAPE GUIDE F
9 KHJ-MC146-02 SPRING,TAPE GUIDE R
10 KHJ-MC147-02 SPRING,TAPE GUIDE F

11 KHJ-MC15A-00 SHAFT
12 KHJ-MC149-00 STOPPER,LEVER R
13 KHJ-MC167-00 COVER,MENBRANE
14 KHJ-MC1A4-00 COVER,ABS
15 KHJ-MC1AA-00 SWITCH,OPERATION
16 KHJ-M4664-00 ABS BOARD ASSY.

17 KHJ-MC1A5-00 DUMMY SPLICE SENS.
18 KHJ-MC1A5-10 SPLICE SENS.8MM 1 OPTION
19 KHJ-MC1AB-00 SCREW,PAN HEAD TAP.
20 90115-02J003 BOLT HEX.SOCKET HEAD

21 92A08-03303 SET SCREW M3X3
22 KHJ-MC1C1-00 PLATE, SPRING ASSY.
23 KHJ-MC1C1-10 PLATE, SPRING ASSY.
24 92902-03200 WASHER PLAIN

25 KHJ-MC141-S0 PARTS,TAPE GUIDE 1 STD
KHJ-MC14A-S0 PARTS,TAPE GUIDE P1 1 1mm Pitch

KHJ-MC14B-S0 PARTS,TAPE GUIDE P4 1 4mm Pitch

KHJ-MC101-01 BODY,FEEDER
KHJ-MC101-02 BODY,FEEDER
KHJ-MC101-03 BODY,FEEDER
KHJ-MC110-00 MOTOR,FEED
KHJ-MC102-00 COVER,FEEDER SIDE 1
KHJ-MC10C-00 SEAL,MAIN LABEL
KHJ-MC10E-00 SCREW,FLAT HEXLOBE
KHJ-MC134-00 GEAR,IDLE F
KHJ-MC135-00 GEAR,IDLE F
KHJ-MC136-01 GEAR,IDLE F
KHJ-MC137-00 GEAR,IDLE F
KHJ-MC138-00 GEAR,DRIVEN
KHJ-MC139-00 SHAFT,IDLE GEAR
KHJ-MC13C-00 PLATE,PUSHER GEAR
KHJ-MC13D-00 SPRING,PUSHER PLATE
KHJ-MC13F-00 SCREW,STAD
KHJ-MC161-01 BOX,TOP TAPE
KHJ-MC161-02 BOX,TOP TAPE
KHJ-MC162-01 COVER,TOP TAPE BOX
KHJ-MC162-02 COVER,TOP TAPE BOX
KHJ-MC162-03 COVER,TOP TAPE BOX
KHJ-MC166-00 BLOCK,P/O TOOTH
KHJ-MC166-01 BLOCK,P/O TOOTH
KHJ-MC166-02 BLOCK,P/O TOOTH
KHJ-MC16F-00 SCREW,FLAT HEAD TAP.
KHJ-MC16J-00 SCREW,FLAT HEAD
KHJ-MC16U-00 TAIL COVER ASSY.
KHJ-MC106-00 PLATE,UNDER
90166-02JA03 SCREW,PAN HEAD
91317-03006 BOLT HEX.SOCKET HEAD
91317-03008 BOLT HEX.SOCKET HEAD
91312-03010 BOLT HEX.SOCKET HEAD
98707-03006 SCREW,FLAT HEAD
KHJ-MC16W-00 PLATE,P/O TOOTH
90112-2AJ006 BOLT HEX.SOCKET HEAD
KHJ-MC10C-00 SEAL,MAIN LABEL
KHJ-MC131-00 SPROCKET ASSY.
KHJ-MC13A-00 SHIM,SPROCKET
KHJ-MC13B-00 BUSH,SPROCKET




KHJ-MC13E-00 BOLT,EXTRA LOW HEAD
KHJ-MC141-02 TAPE GUIDE ASSY.
KHJ-MC144-00 LEVER,TAPE GUIDE R
KHJ-MC145-00 LEVER,TAPE GUIDE F
KHJ-MC146-02 SPRING,TAPE GUIDE R
KHJ-MC147-02 SPRING,TAPE GUIDE F
KHJ-MC15A-00 SHAFT
KHJ-MC165-00 MAGNET,TAIL
KHJ-MC167-00 COVER,MENBRANE
KHJ-MC1A4-00 COVER,ABS
KHJ-MC1AA-00 SWITCH,OPERATION
KHJ-M4664-00 ABS BOARD ASSY.
KHJ-MC1A5-00 DUMMY SPLICE SENS.
KHJ-MC1A5-10 SPLICE SENS.8MM 1 OPTION
KHJ-MC1AB-00 SCREW,PAN HEAD TAP.
90115-02J003 BOLT HEX.SOCKET HEAD
92A08-03303 SET SCREW M3X3
KHJ-MC10E-00 SCREW,FLAT HEXLOBE
KHJ-MC110-10 MOTOR,PEEL
KHJ-MC139-00 SHAFT,IDLE GEAR
KHJ-MC13F-00 SCREW,STAD
KHJ-MC151-00 GEAR,IDLE P1
KHJ-MC152-00 GEAR,IDLE P2
KHJ-MC153-00 GEAR,IDLE P3
KHJ-MC156-00 ROLLER,P/O 1
KHJ-MC156-01 ROLLER,P/O
KHJ-MC156-02 ROLLER,P/O
KHJ-MC159-00 COVER,IDLE GEAR
KHJ-MC154-00 GEAR,IDLE P4
KHJ-MC155-00 GEAR,IDLE P5
KHJ-MC158-00 COVER,IDLE GEAR 1
KHJ-MC16B-00 SHAFT,P/O LEVER 2
KHJ-MC16E-00 SPRING,P/O LEVER
KHJ-MC16H-00 SCREW,PAN HEAD TAP.
KHJ-MC16V-00 P/O LEVER ASSY.
KHJ-MC16V-01 P/O LEVER ASSY.
KHJ-MC16V-02 P/O LEVER ASSY.
