4 Zone Nitrogen Reflow Oven Small Desktop SMD Mounting Machine
4 Zone Nitrogen Reflow Oven Small Desktop SMD Mounting Machine
Specifications
Brand Name :
HWGC
Model Number :
HW-DSQ800-120F
Place of Origin :
CHINA
MOQ :
1
Price :
24500-24800$
Payment Terms :
T/T
Delivery Time :
8 work day
MAX circuit board area :
340*560mm
Vision on :
20000pcs/h
Vision off :
26000pcs/h
Warranty :
1 year
Number of head :
8
Number of feeder :
120
Software :
English
Number of camera :
11
Description

Popularity in China HW-DSQ800-120F SMD Mounting Machine Small Desktop Pick And Place Machine,all in one Pick And Place D

SMT pick and place machine with 50 feeders +4 heads adopts Panasonic servo motor to ensure it is stable and accuracy 2. SMT pick and place machine uses imported Straight guide rail +screw Guide can get faster speed and more stable 3. Four mounting heads work together, under 6 cameras inspection come with 50 feeder positions will make machine working more

Products Description
Specification
Number of Placement Heads
8(high-accuracy)
Number of iC Trays
96
Number of Feeders
120(subject to 8mm feeder)
Positioning Accuracy
0.01mm
Repeated Mounting Accuracy
0.02mm
Range of Mounting Speed
20000-26000Pcs/h
Applicable Components
resistor.capacitor.chip.lamp bead etc.
Supported Maximum Area of PCB
340*560mm
Feeders
NXT electric feeder,vibrating feeder, IC tray etc
Maximum Step Length of Z Axis
50mm
Range of Angle for Components
士180°
Motor
Panasonic AC Servo Motor MINAS A6 series
Driver
Panasonic high-speed DSP driver
Air Supply Requirements
oil water filter,> 60L dust filter and air pressure stabilizer etc
Vacuum Supply of Nozzle
Japanese CKD vacuum generator integrating the high-speed vacuum burst function
Range of Air Supply Pressure
0.5-0.6mp
OS
independent research and development SMT intelligent OS based on Windows
Vision Display
17-inch industrial control display
Cable
German lgus durable flexible cable(10 million times)
Power Supply
220V 50/60Hz
Average Power
1500W
Machine Dimensions
1740*1360*1440mm
Weight
1100Kg


Q:Is it hard to use these machines?
A: No, not hard at all For our previous clients, at most 2 days is enough to learn to operate the machines.

Q:Does your machines have quality certificate?
A: All of our machines have passed CE certificate,ISO14001(BCC),ISO9001(IQNET) and have own paten.

Q:The Warranty of the machine?
A: One year, then the parts will be free for the buyer in the warranty. If there is any doubt in the process of operating the
machine, pls feel free contact us. We will help you in time.

Q:English version for these machines?
A: Yes, and we will reqularly update the software for customers.
