8 Heads ETON PCB pick and place machine E6T Economy Middle Speed
8 Heads ETON PCB pick and place machine E6T Economy Middle Speed
8 Heads ETON PCB pick and place machine E6T Economy Middle Speed
8 Heads ETON PCB pick and place machine E6T Economy Middle Speed
8 Heads ETON PCB pick and place machine E6T Economy Middle Speed
8 Heads ETON PCB pick and place machine E6T Economy Middle Speed
Specifications
Brand Name :
ETON
Model Number :
HT-E6T-1200
Certification :
CE,SIRA,CCC,ISO
Place of Origin :
Shenzhen,China
MOQ :
1 UNIT
Price :
USD10000~40000USD per Unit
Payment Terms :
T/T, L/C, Western Union, MoneyGram, D/P
Supply Ability :
30 UNIT per month
Delivery Time :
Within 15 days after receive the downpayment
Packaging Details :
Standard export wooden case package(Can do as customers' requirement)
Application: :
Economy Middle speed 8 heads ETON led pick and place machine PCB pick and place machine mounting machine E6T
Applicable Components: :
LED chip,IC,capacitors,resistors,shaped components etc.
NO. of head: :
8 PCS
Capacity Speed: :
35000CPH
PCB Size: :
Max:350*1200mm Min:50*50mm
Repeat Precision: :
±0.02mm
Apply to: :
LED light making,(SMT machine)PCB,Hard light board or soft lamp strip,etc.
Feeder Type: :
Electronic feeder(double motor,more precision)
Name: :
smt pick and place machine/led pick and place machine/led chip mounter
No. of Feeder: :
20 PCS
Description
SMT pick and place machine,LED light making machine,LED light production machine.

Product Description

1 .Company Information

ETON has launched its new Middle-speed SMT Pick and Place Machine, Equipped with a newly developed parallel 8 nozzle head, the ETON SMT Pick and Place Machine is capable of mounting a wide variety of parts and improving the mounting speed by up to 20~30%. The ETON Pick and Place Machine is robotic assembly machine for mounting electronic components on a " PCB" in the printed board mounting process. In addition to increasing the number of components mounted per cycle, ETON Pick and Place Machine also includes a new mechanism to improve the mounting speed by automatically changing the recognition sensor height.

2. FRQ :

Intelligent PC Software, could support all kinds of PCB design software, such as rigid PCB, Flexible PCB, FPCB. aluminum PCB etc.


The software introduce


1.lifetime free upgrade,and operate more convenience and easy.
2.Support different kinds of PCB design software in the world
3.Automatic identify mark,any shape type,accuracy and quick
4.Support any multiple PCB set
5.Vacuum detection,automatically dispose and make up if picking fail or pick misaligned
6.Break point continue from any where

Applicalbe industry:

Household appliances industry, Auto electronics industry, Power industry, LED industry, security,instruments and meters industry, communications industry, intelligent control industry, Internet of Things(IOT) industry and military industry

3 . Technical Parameter :

Specifications ETON SMT Pick and Place Machine HT-E6T-1200
Alignment Flying Vision
Number of Spindles 8 heads
Placement Speed 35,000 CPH(Optimum)
Placement Accuracy ±50μm+3σ (Based on the Standard Chips)
Component Range Chip 0402 ~30mm
Board Dimension(mm) 50(L) x 50(W)~500(L) x350(W)
Feeder Capacity 8mm,12mm,16mm,24mm option,according to client products
Power AC 220 50/60Hz,single Phase
Air Consumption 0.5 ~ 0.6MPa(5 ~ 6kgf/cm2)
Mass Approx. 1200kg
External Dimension(mm) 2550(L) x 1650(D) x 1600(H)

4 . Product Image :

8 Heads ETON PCB pick and place machine E6T Economy Middle Speed

5 .Our Services

Excellent Service .

Pre-Sales Service

* Inquiry and consulting support.

* Sample machine testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.


Name: Linda
Mobile/whatsapp/wechat: 0086 13620202581
Skype: lindahe808
Email: linda@eton-mounter.com
QQ: 2423629597
