High Speed PCB Pick And Place Machine Chip Shooter , LED Lights Making Machine
High Speed PCB Pick And Place Machine Chip Shooter , LED Lights Making Machine
High Speed PCB Pick And Place Machine Chip Shooter , LED Lights Making Machine
High Speed PCB Pick And Place Machine Chip Shooter , LED Lights Making Machine
High Speed PCB Pick And Place Machine Chip Shooter , LED Lights Making Machine
High Speed PCB Pick And Place Machine Chip Shooter , LED Lights Making Machine
Specifications
Brand Name :
ETON
Model Number :
HT-E6T-1200
Certification :
CE,SIRA,CCC,ISO
Place of Origin :
Shenzhen,China
MOQ :
1 UNIT
Price :
USD10000~40000USD per Unit
Payment Terms :
T/T, L/C, Western Union, MoneyGram, D/P
Supply Ability :
30 UNIT per month
Delivery Time :
Within 15 days after receive the downpayment
Packaging Details :
Standard export wooden case package(Can do as customers' requirement)
Application: :
small Manufacturer smt pcb mounting machine E6T with 20 feeder 8 head smt pick and place machine
Applicable Components: :
LED chip,IC,capacitors,resistors,shaped components etc.
NO. of head: :
8 PCS
Capacity Speed: :
35000CPH
PCB Size: :
Max:350*1200mm Min:50*50mm
Repeat Precision: :
±0.02mm
Apply to: :
LED light making,(SMT machine)PCB,Hard light board or soft lamp strip,etc.
Feeder Type: :
Electronic feeder(double motor,more precision)
Name: :
smt pick and place machine/led pick and place machine/led chip mounter
No. of Feeder: :
20 PCS
Description
SMT pick and place machine,LED light making machine,LED light production machine.

Product Description

1. Easy to understand way of graphical programming, greatly improve the convenience of operation, automatic visual auxiliary positioning system, accurate, convenient.

2. The selection of a variety of batcher, can satisfy the requirement of different LED packaging components of SMT.

Applicalbe industry:

Household appliances industry, Auto electronics industry, Power industry, LED industry, security,instruments and meters industry, communications industry, intelligent control industry, Internet of Things(IOT) industry and military industry

3 . Technical Parameter :

Specifications ETON SMT Pick and Place Machine HT-E6T-1200
Alignment Flying Vision
Number of Spindles 8 heads
Placement Speed 35,000 CPH(Optimum)
Placement Accuracy ±50μm+3σ (Based on the Standard Chips)
Component Range Chip 0402 ~30mm
Board Dimension(mm) 50(L) x 50(W)~500(L) x350(W)
Feeder Capacity 8mm,12mm,16mm,24mm option,according to client products
Power AC 220 50/60Hz,single Phase
Air Consumption 0.5 ~ 0.6MPa(5 ~ 6kgf/cm2)
Mass Approx. 1200kg
External Dimension(mm) 2550(L) x 1650(D) x 1600(H)

4 .Our Services

Excellent Service .

Pre-Sales Service

* Inquiry and consulting support.

* Sample machine testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.
