Features:
pressure | pressure | compressed air |
Intake pressure setting | 0.5~0.55MPa | |
Injection pressure setting | 0.35~0.38MPa | |
Nozzle injection pressure | ≤0.4MPa | |
Tube | Intake manifold | ¢12tube |
Drain tank water pipe | ¢8tube | |
Cleaning liquid | Cleaning liquid | Industrial deionized water |
Liquid consumption | ≤300cc/h(5cc/min) | |
Capacity of water storage tank | 1200cc | |
Power Supply | Power Supply | AC220~240V |
Plug | 3-Pin | |
Consumption of electricity | ≤0.1Kw | |
Environment | Working environment temperature | -5℃~ (But not frozen.) |
Liquid temperature | 0℃~ (But not frozen.) | |
Working environment humidity | 10~60%RH | |
Environmental humidity of equipment | 10~60%RH | |
dust | 0.1mg/m³(No conductive dust) | |
Corrosive gas | Not allow | |
Others | Outline size | 655(L) x 560(W) x 475(H) |
Weight | (Including cleaning fluid 2000cc) |
Functional features:
Comparison with traditional cleaning:
1. Manual air gun
2. Ultrasonic cleaning
Economic benefits:
Reduce the purchase cost of suction nozzle; after using sme-24 cleaning machine, it can solve the problem of too dirty suction nozzle and scrap, so as to extend the service life.
Reduce unnecessary labor; because the machine adopts automatic cleaning, no special person is responsible for it, and the whole process is automatically completed by the machine.
It can effectively reduce the defective rate of products and improve the productivity of SMT. In the production process, a large part of it is caused by the uneven dirt on the surface of the suction nozzle and the dirt in the inner cavity, resulting in the throwing or mounting displacement, resulting in poor subsequent welding. After using the cleaning machine, the suction nozzle can always be protected in a new state, greatly improving the production efficiency.
Our advantage
ETON is the pioneer of SMT machine field in China which have more than 11 years experiences. And owned CCC, SIRA, CE certificates with 9 invention patents, 112 practical patents, 12 software copyrights of intellectual property technologies.
Oversea market:The products exported to more than 30 countries and regions, including South Korea, India, Vietnam, Tunisia, Egypt,Turkey, Russia, Brazil etc.
Market
Our products had exported to more than 30 countries and regions, including South Korea, India, Vietnam, Tunisia, Egypt,Turkey, Russia, Brazil etc. And here are some of our big customers:
SURYA, POLYCAB, FIEM, RK, GK, TECHNO LED, CALCOM, ACK , KENDAL, RangDong, UNISTAR, and so on.
Packages
Our package step is follow the blowing:
STEP 1: Film packaging to prevent the dust and water;
STEP 2: Packing in a foam cotton stretch a film to protect the outside of the machine;
STEP 3: Vacuum paper package and moisture proof bag, to keep dry during the transportation;
STEP 4: Equip with sturdy wooden boxes to ensure the safety of the machine, then transportation by trucks to the specified port.
Delivery: by sea, air, land transport.
Service
Pre-sale service
Provide suitable production plan
Advise on plant electrical equipment and layout
Sale service
Report machine status in time
Follow up and send test machine video
After-sales service
Software lifetime upgrade
24 hours to deal with problems online
Engineers can arrive on site to teach operation and debug the machine
Regular visit (one year warranty period, spare parts repair free; Once or twice a year after warranty)
