CE Standard LED Strip Super Speed SMT Pick And Place Machine With 9.6 KW Power Consumption
CE Standard LED Strip Super Speed SMT Pick And Place Machine With 9.6 KW Power Consumption
CE Standard LED Strip Super Speed SMT Pick And Place Machine With 9.6 KW Power Consumption
CE Standard LED Strip Super Speed SMT Pick And Place Machine With 9.6 KW Power Consumption
CE Standard LED Strip Super Speed SMT Pick And Place Machine With 9.6 KW Power Consumption
CE Standard LED Strip Super Speed SMT Pick And Place Machine With 9.6 KW Power Consumption
Specifications
Brand Name :
ETON
Model Number :
T9-2S
Certification :
CE,CCC,SIRA,ISO
Place of Origin :
China
MOQ :
1 set
Payment Terms :
T/T
Supply Ability :
50 sets per month
Delivery Time :
30 working days
Packaging Details :
Packing in film package and foam cotton, and covering vacuum bag within sturdy wooden boxes.
Speed :
Double side: 500,000 CPH Single side: 250,000 CPH (Optimum speed)
Heads :
12 PCS
Pcb Thickness :
0.1-0.5 mm
Repeat precision :
±0.05 mm
Power Consumption :
9.6 KW
Total weight :
3100 kg
Components range :
LED 3014/3020/2835/5050 and resistors, capacitors, bridge rectifiers etc.
Mounting mode :
Double rail + Four groups of placement heads
Description

CE standard LED strip super speed SMT pick and place machine

Machine main features

  • Wide components range: High speed modular heads apply to LED 3014/3020/2835/5050 and resistors, capacitors, bridge rectifiers etc.
  • Unique design component leaking detection and individual component refill function. Recognition camera record the component leaking position of PCB, and fill the missing component accordingly.
  • Ultra high speed capacity: 500,000 CPH
  • Intelligent electric feeder,supporting high-speed machine series.
  • Adjust the conveying platform according to various roll to roll strip, range 250±10 mm, the max length range is 1M per cycle.
  • The distance of feeder station can be flexibly adjusted to achieve group picking and group placing, so as to realize the function of two time picking and once placing.
  • The range of feeder station is double of placement four kinds of materials at the same time.
  • Automatic production with identification date, correction and fill missing component automatically.
  • Flight recognition camera, no pause to detect the presence or absence of components, component adsorption state, prevent placement errors.
  • The clamping rod is driven by the air cylinder to correct the materials taken by mounting head.
  • With the function of filling missing component automatically, realize industry 4.0 Unmanned Workshop.
  • Complaint with CE standards.

Machine main parameter

Model T9-2S
Dimension (L)3454*(W)3035*(H)1777 mm
Total weight 3100 kg
PCB size 250(±10)mm* Any length
PCB thickness 0.1-0.5 mm
PCB clamping Vacuum adsorption, cylinder clamping, track width adjustable
Mounting way Group picking and group placing
Mounting mode Double rail + Four groups of placement heads
No. of camera 10 sets (Digital camera)
Software R&D independently
Repeat precision ±0.05 mm
Mounting height ≦5 mm
Mounting speed

Double side: 500,000 CPH

Single side: 250,000 CPH (Optimum speed)
Components range LED 3014/3020/2835/5050 and resistors, capacitors, bridge rectifiers etc.
Power consumption 9.6 KW
No. of feeder station Double side: 136 PCS (Single side: 68 PCS)
No. of nozzles Double side: 136 PCS (Single side: 68 PCS)

Machine application

CE Standard LED Strip Super Speed SMT Pick And Place Machine With 9.6 KW Power Consumption

Certificates

As an experienced manufacturer in SMT machine, we obtained a number of intellectual property technologies, including 14 invention patents, 135 practical patents, 55software copyrights, with our won R&D department for production and inspection. And also earned the oversea certificates as CE, CCC, SIRA,etc.

CE Standard LED Strip Super Speed SMT Pick And Place Machine With 9.6 KW Power Consumption

Related machine

We can provide a whole SMT production line,led light production line:

1.Pick and place machine

2. Loader machine

3. Conveyor machine

4. Stencil printer machine

5. Reflow oven machine

6. Unloader machine

7. Solder paste mixer

8. Roll to roll led strip light assembly machine

CE Standard LED Strip Super Speed SMT Pick And Place Machine With 9.6 KW Power Consumption
