LED Bulb Factory direct supply 10 heads SMD pick and place machine LED chips placement machine

What is SMT Production Process?

Step 1:Solder paste Printing

Operate the stencil printer to print the solder pastes onto the PCB

Step 2:Mounting Part

The PCB board that has been brushed with solder paste will be sent to the pick and place machine for automatic mounting,
and the pick and place machine will automatically pick components and place on PCB.

Step 3 : Reflow Soldering

The PCB board be mounted with components is sent to reflow oven, reflow oven will heat and welding the components with
solder paste on PCB.

Step 4 : Testing

Check whether the PCBA is misaligned or shift.

Features:

1. High-precision industrial cameras solve the problem of precise placement of precision chips such as IC, QFN and other small chips. Place a minimum of 0402 chips.
2. Type: Single-module magnetic linear motor multi-function pick and place machine
3. Adopt imported custom suction nozzle, suck, not easy to lose parts when put, easy to install, durable. Suitable for mounting various special-shaped components.
3. It is equipped with 10 placement heads and 32 feeding stations, can absorb 10 different materials at the same time, and has an automatic replenishment function.
4. The placement accuracy has reached ±0.04mm, which is suitable for placement of high-precision PCB boards.
5. Double-motor electronic feeder, stable feeding, fast feeding speed, no need to repeat calibration.
6. Mounting PCB board size: 400*350mm, the highest can mount components less than 22mm, the smallest can mount 0402 components
7. Mounted products: LED bulb/DOB/driver/power supply/circuit board/home appliance control board/panel light/downlight/and other small PCB board products.
8. Capacity: 30000~35000CPH

After service:

1. Warranty period: one year, any parts that need to be repaired and replaced during the warranty period are free.

2. Service station: India office and Indian engineers can provide you with services faster.

3. After-sales service: Send engineers to your factory for free installation and training.

4. Shipment: Shipment within 30 days after payment.

5. Transportation methods: sea transportation, road transportation, air transportation, etc.

6. Software updates: Enjoy free software updates for life.

About our company:

Our company ETON is the largest manufacturer of high speed pick and place machine. We start from 2011, around 10 years. Our company focusing on “High efficiency Low consumption” in the word, meanwhile ETON is also the largest high-tech manufacturer in China with strong capability of design, R&D, manufacturing, sales and service.

Hong Kong and many technical personnel, after four years of joint research, successfully developed a fast, stable and perfect ETON LED automatic high-speed energy-saving placement machine series products, with its unique technology, strong capacity advantages, and perfect after-sales service system, completely subvert the LED placement machine industry field and solve the production capacity of long light boards and long light strips. Low, high labor cost and other difficult problems, and has been issued a number of certificates and support.

In 2020, ETON Jiangxi Industrial Park was successfully completed, equipped with advanced processing and manufacturing centers and product testing centers to control product quality from the source, and to further standardize and streamline production.

Certificate:
Since its establishment, ETON has been studying technology and seeking further breakthroughs in various aspects. The company has independently developed a number of intellectual property technologies. In fact, there are 9 invention patents, 112 utility patents, and 12 software copyrights.

SMT line:

Mode of transportation:
Support sea transportation, railway transportation, air transportation, etc.

FAQ:

Q: Who is your client?

A: We have exported machine to different countries, such as India, Egypt, Korea, Turkey, Brazil etc. Such as FSL,ETI,KONKA,OPPLE,MLS are our client, In India such as RK, Surya, skyquad are our client.

Q: How is the breakdown rate of machine?

A: Our machine is very stable, the breakdown rate is less than 0.001.

Q: Is your software interface in English?

A: English interface and Chinese interface are both avaible.

Q: Machine is easy to operate?

A: Machine is easy to operate, usually 3 to 5 days training of operating is enough.

Add: If you have any questions, please feel free to contact me!
