SMT PCB Magazine Unloader 50*80 - 445*330mm For L-Size PCBs
SMT PCB Magazine Unloader 50*80 - 445*330mm For L-Size PCBs
Specifications
Brand Name :
INFITEK
Model Number :
UL-L-TN
Certification :
CE
Place of Origin :
China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Packaging Details :
crate
Application :
SMT Magazine Type Unloader for L-size PCBs
Description :
Magazine Type PCB Loader Unloader L-Type
Brand :
INFITEK
Model :
UL-L-TN
PCB Size :
50*80-445*330 mm
Features :
Easy to operate, durable, and with long life span
Warranty :
1 Year Warranty
Reliability :
Industrial grade
Packaging :
Wooden Box / Crate
Description

Automatic Magazine Type PCB Unloader for L-size PCBs - 50*80-445*330mm PCB Sizes | INFITEK Board Handling Equipment

INFITEK UL-L-TN Automatic Unloader is a type of Magazine Type PCB Unloader used in SMT Production Line. This board handling equipment was designed by INFITEK using ideas and designs and problems that were independently developed and combined with original and branded parts to produce a quality, high level of durability, reliable durability, and above all, ensured a high level of user safety. The UL-L-TN Automatic Magazine Type PCB Unloader is the model designed for use with L-size PCBs. It has an adjustable width that can accommodate PCBs with sizes from 50*80-445*330mm.

SMT PCB Magazine Unloader

Model: UL-L-TN

Applicable PCB Sizes: 50*80-445*330 (mm)

PCB Magazine Size: 460*400*563 (mm)

Machine Dimensions: 2065*845*1250 (mm)

Machine Weight: 220 kg.

Features:

  • Strong, firm, and stable design
  • User-friendly soft touch LED membrane control panel
  • Top & bottom pneumatic clamps to secure magazine rack
  • No PCB breakage guarantee because of the special gas circuit design
  • Automatically diagnosing fault code display function
  • Wear-resistant cable and have a long service life
  • SMEMA compatible

TECHNICAL PARAMETERS
Description This unit is used for unloading and of PCBs using a PCB Magazine
No. of magazine Loader: upper 1, lower 2 / Unloader: upper 1, ,lower 1
Time feed PCB Seconds 6 Approx. or specify
Magazine replacement time indexing pitch 10.20.30.40mm or specify
Power supply AC1P110V/220V
Power Max300VA
Air pressure 4-6bar,10ltr/min max
Transport height 900±20mm (or customized)
Transport direction From left to right or right to left

Operation Diagram:

SMT PCB Magazine Unloader 50*80 - 445*330mm For L-Size PCBs
