Specifications
Brand Name :
INFITEK
Model Number :
LV-330W-TN, LV-460W-TN
Place of Origin :
China
MOQ :
1 unit
Price :
Negotiated
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Packaging Details :
crate
Application :
PCB Vacuum Loading in SMT Production Line
Description :
SMT Vacuum Loader
Model :
LV-330W-TN, LV-460W-TN
Features :
Minimize clearance between conveyor
Brand :
INFITEK
Reliability :
design for Industrial use
Packaging :
Wooden Box package
Warranty :
1 Year
Description

Vacuum Loader SMT Assembly Line Translation Type Suction Machine

SMT Vacuum Loader, Translation type suction machine, High-quality, and Durable SMT Link Conveyors

SMT Vacuum Loader is used for automatic loading operation of PCB in SMT Production Line. INFITEK Series Translation type suction machine has a touch screen control panel making this machine convenient and easy to operate. Equipped with a stepper motor, this SMT vacuum loader equipment provides smooth and precise translation. Infinite Vacuum Loading Machine is designed with a fully enclosed structure to ensure safe operations. Infinite SMT Vacuum Loader is available for different PCB sizes and we also customized machine size depending on customer's requirements.

Features:

Convenient operation of touch screen control panel

The vacuum loader structure is fully enclosed to ensure a safe level of operation

Adjust the position of the suction nozzle to ensure the circuit boards are clamped

Parallel and smooth width adjustment (lead screw)

Smooth and precise translation (stepper motor)

Minimize clearance between conveyor

The machine size can be specified

SMEMA compatible

TECHNICAL PARAMETERS
Description This unit is used for automatic loading operation into the transceiver board
Cycle time Approx. 12seconds or specify
Power supply AC1P110V/220V
Power 150V max
Air pressure 4-6bar,30ltr/min max
Transport height 900±20mm (or customized)
Transport direction From left to right or right to left

SPECIFICATIONS
Model Dimension (L*W*H MM) PCB size (MM) Weight (KG)
LV-330W-TN 600*1002*1300 50*50-450*330 130
LV-460W-TN 800*1270*1300 50*50-530*460 150

Infinite Automation is focusing on providing alternative SMT Factory Automation and Production Solutions. We have a factory warehouse in China and offer sales of new and used SMT machines. ​Infinite Automation provides full SMT assembly line solutions, we offer brand new and best conditions second-hand/pre-owned SMT machines and equipment-Solder Paste Printer, SMT Mounter, AOI, SPI, Link Conveyors, Industrial Cleaners, and all factory automation products.
