Specifications
Brand Name :
INFITEK
Model Number :
BD-L-TN, BD-XL-TN
Place of Origin :
China
MOQ :
1 unit
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Packaging Details :
crate
Price :
Negotiated
Application :
Multi-function PCB Buffer machine
Description :
Multifunctional Vertical Type Buffer
Brand :
INFITEK
Model :
BD-L-TN, BD-XL-TN
Features :
Multi Function Vertical Buffer unit is used as a buffer between SMT machines
Warranty :
1 Year Warranty
Reliability :
design for Industrial use
Packaging :
Wooden Box package
Description

Multifunctional Vertical Type Buffer SMT Assembly Line PCB Conveyor

Multifunctional Vertical Type Buffer, Modular Design SMT Link Conveyor

INFITEK Multifunctional Vertical Type Buffer is used as a buffer between SMT machines. This multi-function buffer conveyor has a maximum capacity to buffer up to 25 pcs. PCBs and also can be specified according to customers' requirements. INFITEK Multifunctional Vertical Type Buffer Conveyor has an easy-to-use membrane control panel. INFITEK Multifunctional Vertical Type Buffer can be set in three (3) operation modes; FIFO, LIFO, and Pass-through. INFITEK Vertical Type Buffer is made from high-quality materials and with an enclosed design to ensure the highest level of safety. Equipped with a lead screw for smooth and easy rail width adjustments. INFITEK Multifunctional Vertical Type Buffer uses a wear-resistant anti-static belt for transmission.

Features:

User-friendly membrane control panel

Use wear-resistant anti-static belts for transmission (convenient belt replacement)

Three operation modes: FIFO, LIFO, Pass-through

Parallel and smooth width adjustment (lead screw)

Fast, smooth, and accurate retrieval positions

The enclosed design ensures the highest level of safety

Small machine footprint

SMEMA compatible

TECHNICAL PARAMETERS
Description This unit is used as a buffer between the SMT machine
Cycle time Approx.10 seconds
Maximum PCBs magazine 25pcs or specify
Power supply AC1P110V/220V
Power Max 250VA
Transport height 900±20mm (or customized)
Transport direction From left to right or right to left

SPECIFICATIONS
Model Dimension (L*W*H MM) PCB size (MM) Weight (KG)
BD-L-TN 1000*790*1640 50*50-445*350 190
BD-XL-TN 1200*900*1640 50*50-530*460 240
