Automatic Lead - Free SMT Soldering Machine PC + PLC Control N450 Model
Automatic Lead - Free SMT Soldering Machine PC + PLC Control N450 Model
Automatic Lead - Free SMT Soldering Machine PC + PLC Control N450 Model
Automatic Lead - Free SMT Soldering Machine PC + PLC Control N450 Model
Automatic Lead - Free SMT Soldering Machine PC + PLC Control N450 Model
Automatic Lead - Free SMT Soldering Machine PC + PLC Control N450 Model
Specifications
Brand Name :
JAGUAR
Model Number :
N450
Certification :
CE ISO
Place of Origin :
China
MOQ :
1Set
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30 Sets/month
Packaging Details :
Wooden Case ; 4700x1620x1950mm ; 1Set Per 20GP
Delivery Time :
3-7days
Name :
Wave Welding Machine ; Heating Machine ; SMT Machine
Max PCB Size :
30-350mm
Finger Material :
Ti
Usage :
SMT ; LED ; SMD ; And Son on
Control :
PC + PLC Control
Application :
PCB Assembly ; SMT
Heating Method :
Hot Air
Heating Zone :
4
Other :
Accept Customize
Description

N450 Lead-free Hot Air Wave Soldering Machine N450 High-end Automatic Intelligent Wave Welding Machine

JAGUAR N350 Lead-free Hot Air Wave Soldering Machine, as a member of Jaguar High-end series of Wave Soldering, standard configured 3 pre-heating zone, and totol pre-heating zone length up to 1600mm, pre-heating zone structure is independ control, it's better to ensure pre-heat effect, and finally to ensure soldering effect. 3 kinds of material options (316L Stainless Steel ; Ti ; Cast Iron Enamel)

Model No. JAGUAR N450
Number of heating zones 4
Length of heating zones 2000mm
Total/steady consumption 30KW/8-11KW
Air supply 0.5MPa
Preheating style Hot air
Preheating consumption 220V 8KW
Control method PC +PLC
Range of temp. setpoint Room temperature---300ºC
Preheating time About 10-15mins for setting 150ºC
Solder Application Lead-free / Sn-Pb
Solder pot capacity 400KG
Solder pot temperature 300ºC
Solder pot material Cast Iron Ceramic Coating/TA1 Titanium/316 Stainless Steel
Heater consumption 380V 8KW
Solder temp. control method PID+SSR
Wave motor consumption 1KW 220V
Wave height Control Inverter
Solder melting time About 180mins for setting 250ºC
PCB width 60-450mm
Product clearance Top 120mm(option 160mm) Bottom 15mm
Conveyor speed 0-2000mm/min
Process height 750+/-20mm
Conveyor direction L→R (R→L optional)
Conveyor Inclination 4-7 º
Process width adjustment Manual
UPS Option
Nitrogen structure Option
Flux pressure/capacity 3-5 bar/6.5L
Weight 1100KG
Power Requirement 3P5W,380/220V 50Hz 63A
Dimensions 4300(L)*1400(W)*1560(H)
Advantages

1. Energy-saving, lead-free application, meet with environmental protection requirement and user friendly designed

2. Automatic power system, inverter control, automatic board in-load feature.

3. Flux sprayer using transverse Japanese spray nozzle and driving by pneumatic cylinders. PLC controlled, accurate and reliable.

4. Preheating system uses four independent temperature control so as to ensure the excellent heat preservation, temperature uniformity, temperature accuracy in ±2ºC.

5. Titanium solder fingers, high strengthened double v-groove with tin resistant
