Specifications
Model NO. :
FD25
Fuel :
Diesel
Load center :
>500mm
Lift height :
3000mm-6000mm
Condition :
New
Engine :
China / Japan for Choice
Mast :
Duplex/Full Free Lift Mast
Tire :
Pneumatic Tire
Transmission :
Automatic Transmission
Attachements :
Side Shifter, Clamps, Positioner Ect
Options :
LED Light, Lux Seat, Fan, Solid Tire Ect
Color :
Customer Customized
OEM :
Yes
Transport Package :
Container Shipment
Specification :
3750kg
Trademark :
SNSC
Origin :
China, Wuhu
HS Code :
84272090
Supply Ability :
500/Months
After-sales Service :
Online
Warranty :
15 Months
Cab Location :
Adjustable
Type :
Ordinary Combustion Forklift
Power :
Diesel Engine
Load Capacity :
1T - 5T
Customization :
Available | Customized Request
Place of Origin :
china
Brand Name :
snsc
Certification :
CE/ISO
MOQ :
1 unit
Price :
negotiable
Packaging Details :
shipped by container
Delivery Time :
30-45 Days
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Description


Side Shifter 2.5ton Diesel Caretilla Autoelevadora Diesel Engie Forklift Easy Maneuverability
Side Shifter 2.5ton Diesel Caretilla Autoelevadora Diesel Engie Forklift Easy Maneuverability
Specifications Unit FD25
1 Characteristics Power diesel
2 Rated Capacity kg 2500
3 Center of load mm 500
4 Lifting height mm 3000
5 Free lifting height mm 135
6 Forks L×W×H mm 1070x122x40
7 Tilt Forward/Backward . 6/12
8 Min.turning radius mm 2240
9 Min.ground clearance(Mast) mm 110
10 Overhead guard height mm 2120
11 Height from seat to overhead guard mm 943
12 Front overhang mm 473
13 Perf Max.traveling speed(loaded) km/h 19
14 Max.lifting speed(loaded/empty) mm/s 470/510
15 Drawbar pull/Gradeability kN/% 17/20
16 Dimensions Overall length (without fork) mm 2570
17 Overall width mm 1175
18 Mast lowered height mm 1990
19 Mast extended height mm 4000
20 Chassis Tire Front 7.00-12-12PR
21 Rear 6.00-9-10PR
22 Wheelbase mm 1600
23 Tread width Front/Rear mm 970/970
24 Curb weight None-load kg 3750
25 Powertrain Battery Voltage/Capacity V/Ah 12/90
26 Engine Model Mitsubishi S4S engine
27 Rated power kw/r.p.m 38/2300
28 Rated torque Nm/r.p.m 176/1800
29 Cylinder amount 4
30 Bore×Stroke mm 94x120
31 Displacement 3.331
32 Fuel tank L 60
33 Transmission 1/1 automatic transmission
34 Working pressure MPa 17.5

Side Shifter 2.5ton Diesel Caretilla Autoelevadora Diesel Engie Forklift Easy Maneuverability
Engine China xinchai engine/Japan Mitsubishi & iszu engine
Transmission Auto/manual hand/machinery
Lifting height 3000-6000mm
Mast Standard duplex/Duples full free lift/Triplex full free lift
Tire Pneumatic tire/solid tire/double front tire/off road tire
Overhead guard Gird type/water-proof type
Light front lamp/rear lamp/truning linght/combination light
Mirror Left and right mirror/Rearview mirror/wide view mirror
Seat Standard seat/ seat with belt/seat with arm/suspension seat
Fork length 920mm/1070mm/1220mm/1570mm ect
Color Green/yellow/red/customer customized
Certificat CE &ISO &EPA
Tool box Yes
Maintenance manual Yes
Operation manual Yes
Spare part manual Yes
Free Spare part Yes

Side Shifter 2.5ton Diesel Caretilla Autoelevadora Diesel Engie Forklift Easy ManeuverabilitySNSC Forklift have strict indoor and outdoor quality control system which includes braking performance, the inclination angle of the mast, detection of chassis oil leakage, counterweight, loading, lifting, tilting, turning, climbing, etc.

To ensure our customers can receive high performance forklifts, all of our forklifts will be tested again before delivery. If notpassed any test, the forklift is not allowed leave from our factory. If the storage time exceeds 1 month, we need to do regular maintenance and testing until it leaves the factory.

Side Shifter 2.5ton Diesel Caretilla Autoelevadora Diesel Engie Forklift Easy Maneuverability
We have all kinds of forklift , here is our forklift catalogue for your choice:
1)Diesel forklift truck capacity from 1.5ton to 16ton;
2) Electric forklift truck capacity from 1.5ton to 3.5ton;
3) LPG gas gasoline forklift truck capacity from 1.5ton to 7ton;
4) Warehouse equipment, includes electric pallet truck, electric reach truck, electric stacker, electric trailer
5) Rough terrain forklift truck capacity from 1.8-5ton;
5) Other special function forklift, eg: cold warehouse electric forklift, explosion-proof forklift, renting business forklift.

Side Shifter 2.5ton Diesel Caretilla Autoelevadora Diesel Engie Forklift Easy Maneuverability
SNSC Forklift is shipped by container. Packaging&Shipping 1*20'GP - 3 Units, 1*40'GP - 5 Units

Covered Forklift In Container Shipping with Tool Box, Catalogue, Gloves and Operation and Maintenance Manuals and Spare Parts together.

Forklift Warranty Time period for SNSC Forklift is 15 Months or 2500 Working Hours begins from the forklift arrival date of oversea port, deponds on which come first.

Side Shifter 2.5ton Diesel Caretilla Autoelevadora Diesel Engie Forklift Easy Maneuverability
We are first calss in Chinese fork lift manufactures and top 20 in the world,with 130,000 square meters production area,over 500 employees,30,000 units forklift truc production capacity per year ,5000 sets export volume.our R&D research is in Britain, and we invested over 600 million in fork lifter factory, use advanced equipments to realize over 90% automatic production, e.g.: welding robot.

Every forklift part is self produced; we have 5 series and over 200 models to meet customers' different demands, we can do all kinds of lifting height mast according your different working conditions.
