50 M3 Ready Mobile Batching Plant 50 Cbm Wet Concrete Batching Plant Cement
50 M3 Ready Mobile Batching Plant 50 Cbm Wet Concrete Batching Plant Cement
Specifications
Brand Name :
SINOWAY
Model Number :
SWCBP600
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
D/A, L/C, D/A, D/P, T/T, Western Union
Supply Ability :
60 set per month
Delivery Time :
30 days
Packaging Details :
Nude
Capacity Per Hour :
50m³/h
Mixer capacity :
1.0 m³
Discharge height :
3.8 m
Motor power :
2x22kw
Cycle time :
50 s
Total power :
110kw
Description

Concrete Mixing Plant

A concrete plant, also known as a batch plant orbatching plant or a concrete batching plant, is equipmentthat combines various ingredients to form concrete. Some of these inputs include water, air, admixtures, sand, aggregate, fly ash, silica fume, slag, and cement. There are two main types of concrete plants: Dry mixing plants and Wet mix plants, and also plants that containboth a transit mix side and a central mix side whileutilizing common material storage points. A concrete plant can have a varietyof parts and accessories, including: mixers, cement batchers, aggregatebatchers, conveyors, radial stackers, aggregate bins, cement bins, heaters, chillers, cement silos, batch plant controls, and dust collectors.

SINOWAY concrete mixing plant is a combinational device used to mix concrete in centralized.Because of its mechanization, high degree of automation, so the productivity is also high, and to ensure the quality of concrete and save cement.There are many different types and components of the concrete mixing plants, the basic structure includes: Feeding system, measuring (weighing) system, mixing system, electrical system and auxiliary equipments (such as air compressor, water pump etc. ). They are used to transport, feed, store, batch, weigh, mix and discharge the concrete raw materials: Cement, water, sand, crushed stone, admixture and additive.

Highlights

Adopting horizontal twin-shaft compulsory mixer. The aggregate is measured accumulatively by electric scale
Water and additive is measured accurately under the control of the computer. The whole machine is controlled by computer which makes operation easy
The main electric components are from famous brand.

Main Technical specifications 　
Productivity 40~50 m³/h
Model of the mixer SWM1000
Power of the mixing motor 2×22 kW
Cycle time 50 s
Volume of the mixer 1.0 m³
Aggregate size ≤60 mm
Capacity of the powder silo 2×100 ton
Capacity of the aggregate bin 13 m³
Number of aggregate bin 3
Conveying capacity of the Inclined belt conveyor 150 t/h
Discharge height 3.8 m
Total power 110 kW
weighing range and accuracy of the stone 2000±2% kg
Weighing range and accuracy of the sand 2000±2% kg
Weighing range and accuracy of the cement 600±1% kg
Weighing range and accuracy of fly ash 300±1% kg
Weighing range and accuracy of the water 300±1% kg
Weighing range and accuracy of the admixture 30±1% kg
Working voltage and frequency 380 V/50 Hz
Control voltage DC24 V
