3 Axle Low Deck Gooseneck Trailer 60 Ton Cargo Semi Trailer Lowboy Flatbed
3 Axle Low Deck Gooseneck Trailer 60 Ton Cargo Semi Trailer Lowboy Flatbed
Specifications
Brand Name :
Sinoway
Model Number :
SWCST603C
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1 unit
Price :
Negotiation
Payment Terms :
D/A, L/C, D/P, T/T, Western Union
Supply Ability :
1000 pcs per month
Delivery Time :
30 days
Packaging Details :
Nude
Payload capacity :
60 ton
Axles :
BPW
Tire :
12R22.5
Condition :
Brand new
Shiping terms :
FOB, CFR CIF
Warranty :
One year
Description

Semi Trailer Features:
Apply to the transport loose cargo light, soft, with a low center of gravity and light weight, the quality of the utilization factor, carrying capacity and other characteristics
Overall assembly and disassembly convenient, can be more than one car, van, car warehouse gate, tailgate car at the same time.
Innovative design, tailored to local transport environment analysis on the basis of full understanding of, learn from the advanced design concept, many innovative.
Advanced means of production technology and perfect testing equipment to protect the the product overall structure is reasonable, reliable performance.
Frame body Q345B high strength structure steel, automatic submerged arc welding throughout beams, and other cross-section main stringers structure for optimum carrying effect.
Well-known brand axles, suspension systems, high performance, and reliable to use, to ensure the good performance of the vehicle.
Full braking and electrical systems at home and abroad in accordance with ISO standard, optional ABS system, braking, lighting is absolutely safe and reliable.
Frame overall spray primer treatment, paint spraying fine surface quality of maritime anti-corrosion standards.

Overall dimension 12660×2680×2800 mm
Internal dimension 12500×2300×600 mm
Axle 13Ton Fuwa(braking pad width 220mm)
Tyre 1200R20-18PR
Rim 8.5-20
Leaf spring 90mm width*10pcs*13mm thickness
Braking system 2 line air braking system with air tank,emergency relayvalve,braking chambers and mechanical slack adjusters
Electrical system connector.parking .stop,reverse,number plate and
Suspension indicator lights.rear lights conform to European
Relay valve standard,rear front and side reflectors,Reinforced German WABCO
Landing gear To load 1*40" or 2*20" containers
Kingpin 3.5” Stored chamber
Twist Lock 3mm Flatplate type
Chamber 14/16mm,using the highly quality Q345 steel
Floor 600mm side board
Upper and lower wing plates 14/16mm,using the highly quality Q345 steel
Board 600mm side board
Hand lock Standard Standard
Main beam 500mm,webplate:6mm using the highly quality Q345 steel
Side beam 16# channel steel
Cross beam Square tube
Reflectors Red triangle reflectors at the rear of the trailer and on side
Light LED
Payload 60 ton
