Q345 Carbon Steel Low Bed Container Trailer Heavy Duty Leaf - Spring Suspension
Q345 Carbon Steel Low Bed Container Trailer Heavy Duty Leaf - Spring Suspension
Specifications
Brand Name :
Sinoway
Model Number :
SWTST7004
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1 unit
Price :
Negotiation
Payment Terms :
D/A, L/C, D/P, T/T, Western Union
Supply Ability :
1000 pcs per month
Delivery Time :
30 days
Packaging Details :
Nude
Max. Payload :
7000kg
Material :
Q345 Carbon steel
Cylinder :
HYVA
King pin :
3.5'' JOST bolting king pin
Axles :
3×16T FUWA axle+1×12T FUWA front lifting axle
Description

Q345 Carbon Steel/HYVA 214 Cylinder/3 FUWA Axles/WABCO Relay Valve Semi Trailer

Main Technical specification 　
Dimension 　
Length 11340 mm
Width 2500 mm
Loading height 2980mm @ unload
Weight 　
Tare weight 13500 kg
Max. Payload 70000 kg
Chassis Structure 　
Material Q345 Carbon steel
Upper＆lower wingplate 16/20mm
Mainbeam 500mm
Webplate 10mm
Cylinder HYVA 214
Cargo body plate thickness Bottom 8mm, side 6mm
OEM Parts Configuration 　
King pin 3.5'' JOST bolting king pin
Landing gear One speed, JOST C200
Suspension Leaf-spring suspension
Axles 3×16 T FUWA axle + 1×12 T FUWA front lifting axle
Rims 8.5-20/16
Tires 12.00R20/16
Brake system Dual air brake system, WABCO relay valve. No ABS brake system
Brake chamber Type 30/30 on rear two axles, Type 30 on front axle
Electrical system 24 volt lighting system, 7-way receptacle
Others 　
Spare tire & carrier 1 pcs equipped beside the chassis without spare tires
Side guard SINOWAY standard
Tool box Equipped one on the right side
