Dust Test Chamber IP5X IP6X Programmable Environmental Testing Equipment

Standards:

La and Lb in GB2423.37-89; GB 4208-98； IEC60529

Description:

This test chamber adopts manual simulation of dust environment to inspect the dust-proof ability of the tested products. The specific requirements and qualification criteria shall be in accordance with GB4208-93 (IEC60529-2001) or relevant product standards.

This test box is mainly used to evaluate whether the shell and sealing element can guarantee the good working performance of equipment and components during the sand and dust prevention test of electronic and electrical products.

The dustproof test chamber is designed and manufactured in accordance with GB4208-93 (equivalent to IEC60529-2001) Degrees of Protection Provided by Enclosures (IP Code). It is applicable to the sand and dust test of electrical products with the first characteristic digits of 5 and 6 (IPX5 and IPX6).

Note: This test chamber can meet the requirements of GB2423, GB4706, GB4208 and DIN for the protection grade test of the housing of household appliances, low-voltage appliances, automobiles and motorcycles. This device cannot meet the sand dust test with wind source in GJB150.

Specification:

Tank size	600*600*600mm ,800*800*800mm ,1000*1000*1000mm
Liner material	High grade stainless steel plate SUS304
Compliance with standards	GB4208-93
Outer box size	1750*1250*1450mm
Outer box material	High grade stainless steel plate SUS304
Box door	Large tempered glass observation window
Air duct system	The unique air duct design ensures that the box generates non layered vertical circulating air flow
Temperature in the box	RT+10~60°C
Relative humidity in the box	45%~75%RH
Nominal wire diameter	50um
Nominal distance between lines	Not more than 70um
Amount of dust in the box	2Kg/m
Air velocity	≤2m/s
Amount of talcum powder	2kg~4kg/ m3
Dust blowing time	0~9999.9h can be set
Control system	Imported high-precision PID digital display instrument
Safety protection device	Instrument overtemperature protection function, power supply phase loss protection, leakage circuit breaker
Power Supply	AC220V 50Hz
air temperature	0～35℃
relative humidity	25%～75%RH
Input power	About 2KW
