GCL Solar Panel 525w 530W 535W 540W 545W 550W555W 560W 144cells Half Cell Monocrystalline PV High Output
GCL Solar Panel 525w 530W 535W 540W 545W 550W555W 560W 144cells Half Cell Monocrystalline PV High Output
GCL Solar Panel 525w 530W 535W 540W 545W 550W555W 560W 144cells Half Cell Monocrystalline PV High Output
GCL Solar Panel 525w 530W 535W 540W 545W 550W555W 560W 144cells Half Cell Monocrystalline PV High Output
GCL Solar Panel 525w 530W 535W 540W 545W 550W555W 560W 144cells Half Cell Monocrystalline PV High Output
GCL Solar Panel 525w 530W 535W 540W 545W 550W555W 560W 144cells Half Cell Monocrystalline PV High Output
Specifications
Brand Name :
GCL
Model Number :
GCL-M10/72H
Certification :
CE
Place of Origin :
China,Jiangsu
MOQ :
1000
Price :
＄0.28 watt
Payment Terms :
T/T
Supply Ability :
10000
Delivery Time :
5-8 work days
Pmax[W :
525w
Vmp[V] :
41.21V
lmp[A :
12.74A
Voc[V] :
49.05V
Pmax [WI :
397. 2W
Vmp [VI :
38.22V
SIZE :
2256x1133x35 mm
Weight :
27.5KG
Description

GCL Solar Panel 525w 530W 535W 540W 545W 550W555W 560W 144cells Half Cell Monocrystalline PV High Output

Specifications
power output 525W 530W 535W 540W 545W 550W 555W 560W
operating voltage of the maximum power point 41.21V 41.48V 41.77V 42.06W 42.35W 42.64W 42.93W 43.22W
Operating current at the maximum power point 12.74A 12.78A 12.81A 12.84A 12.87A 12.90A 12.93A 12.96A
open circuit voltage 49.05V 49.28V 49.51V 49.75V 49.98V 50.22V 50.45V 50.68V
Short circuit current 13.53A 13.57A 13.60A 13.63A 13.66A 13.70A 13.73A 13.76A
The efficiency of the component 20.5% 20.7% 20.9% 21.1% 21.3% 21.5% 21.7% 21.9%
The power of tolerance 0-+5W
Structure performance
Battery sheet arrangement 144 pieces (6 x24)
Component size 2256x1133x35 mm
weight 27.5 kg
glass 3.2mm high permeability, anti reflection coated toughened glass
The back white
A border Anodized film aluminum alloy
wiring Protection level IP68
Box of cable 4 mm square, 280 mm positive wire, 280 mm negative wire
Number of diodes 3
Wind/snow pressure 2400/5400 mpa
The connector The MC is compatible with
