EPC Solar Panel Ground Mounting Systems High Strength Horizontal Vertical Installation Angle 10-60°
EPC Solar Panel Ground Mounting Systems High Strength Horizontal Vertical Installation Angle 10-60°
EPC Solar Panel Ground Mounting Systems High Strength Horizontal Vertical Installation Angle 10-60°
EPC Solar Panel Ground Mounting Systems High Strength Horizontal Vertical Installation Angle 10-60°
EPC Solar Panel Ground Mounting Systems High Strength Horizontal Vertical Installation Angle 10-60°
EPC Solar Panel Ground Mounting Systems High Strength Horizontal Vertical Installation Angle 10-60°
EPC Solar Panel Ground Mounting Systems High Strength Horizontal Vertical Installation Angle 10-60°
EPC Solar Panel Ground Mounting Systems High Strength Horizontal Vertical Installation Angle 10-60°
Specifications
Brand Name :
TIANFON
Model Number :
Solar Panel Ground Mounting Systems
Certification :
SGS,ISO 9001,ISO 14001,OHSAS 18001
Place of Origin :
China
MOQ :
1000 Watt/Watts
Price :
US $0.05-0.18 / Watts
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100000 Watt/Watts per Week
Delivery Time :
within 15-25 work days after receipt deposit
Packaging Details :
1.Carton box,wooden pallet,belt bundle packing and other kinds of package ensure the products safety and waterproof. 2.Customized packing
Name :
Suitable Solar Module Mounting Solution
Application :
Utility-scale
Material :
Hot galvanized steel
Module Orientation :
Horizontal / Vertical
Applicable Module :
Any size
Warranty :
10 years
Description

High Strength Suitable Solar Module Mounting Solution for EPC

The Solar Mounting structure is used to fix the solar PV panels and gives a support and inclination to the system.

These customized mounting structures are manufactured from cold rolled Zn-Al/Zn coated steel that offers high corrosion resistance, weight optimization and quick installation.

They can be mounted on a concrete foundation or ground screws.Customized tilt angles meet the complex requirements of the construction site and use effectively energy of the sun.

Engineering Specifications:

►Installation Site: ground, flat, tilt roof, tile roof, vitreous tile, any suitable area

►Installation Angle: 10-60 °

►Snow Load: up to 1.4 KN/m2 (40psf)

►Wind Load: up to 36.9 m/s (150 km/h)

►Wind Pressure: up to 66.42 KG/m2

►Module Orientation: Horizontal / Vertical

►Applicable Module: Any brand of PV solar power panel module

►Color: Natural, Silver, Gray, or Customized

►Frame material: Hot-dipped Galvanised MS Angles, Stainless Steel 304, aluminum alloy 6063-T5

►Warranty: 10 years

►Standard: GB/T13912-2002 or AS/NZS 1170 or any other International standard
