Specifications
Place of Origin :
Anhui, China
Brand Name :
Deye
Model Number :
SUN-5K-12K-SG01LP1
Input Voltage :
1000V
Output Voltage :
220 Vac/ 230 Vac/ 240 Vac
Output Current :
40A
Output Type :
Single, Triple, Three Phase
Size :
840W*345H*375D
Type :
DC/AC Inverters
Inverter Efficiency :
98.4 %
Certificate :
CEI 0-21, VDE-AR-N-4105, IEC61727, IEC62116
Warranty :
5 YEARS, 5 Years
Weight :
35.0 kg (26.5 lb)
Product name :
Deye Inverter
Inverter type :
Three Phase Hybrid Inverter
Battery Voltage :
160 ~ 700 Vdc
Battery type :
Gel and Lithium battery
Keyword :
Deye Hybrid Inverter
MPPT voltage range :
150V-850V
Maximum PV Array Power :
6500 Wp
Lead Time :
10 working days after receive the payment
Application :
Hybrid Solar Power System
MOQ :
2 pieces
Price :
$1,080.00/pieces 2-49 pieces
Description
Product Description
Low Voltage Wifi Solar Inverter Deye SUN-5K-SG03LP1-EU 3.6kw 6kw 8kw For Solar System
Low Voltage Wifi Solar Inverter Deye SUN-5K-SG03LP1-EU 3.6kw 6kw 8kw For Solar System
Model
SUN-5K-SG01HP3-EU-AM2
Battery Input Data
Battery Type
Lithium-ion
Battery Voltage Range (V)
160~700V
Max. Charging Current (A)
37
Max. Discharging Current (A)
37
Number of battery input
1
Charging Strategy for Li-Ion Battery
Self-adaption to BMS
PV String Input Data
Max. DC Input Power (W)
6500W
Max. DC Input Voltage (V)
1000
Start-up Voltage (V)
180V
MPPT Range (V)
150V-850V
Full Load DC Voltage Range (V)
195-850
Rated DC Input Voltage (V)
600
PV Input Current (A)
20A+20A
Max. PV ISC (A)
30A+30A
Number of MPPT / Strings per MPPT
2/1
AC Output Data
Rated AC Output and UPS Power (W)
5000W
Max. AC Output Power (W)
5500W
Peak Power (off grid)
1.5 times of rated power, 10 S
AC Output Rated Current (A)
7.6/7.3
Max. AC Current (A)
13
Max. Continuous AC Passthrough (A)
40A
Output Frequency and Voltage
50/60Hz;3L/N/PE 220/380Vac，230/400Vac
Grid Type
Three Phase
DC injection current (mA)
<0.5%1n
Efficiency
Max. Efficiency
97.60%
Euro Efficiency
97.00%
MPPT Efficiency
99.90%
Protection
PV Input Lightning Protection
Integrated
Anti-islanding Protection
Integrated
PV String Input Reverse Polarity Protection
Integrated
Insulation Resistor Detection
Integrated
Residual Current Monitoring Unit
Integrated
Output Over Current Protection
Integrated
Output Shorted Protection
Integrated
Surge protection
Integrated
Output Over Voltage Protection
DC Type II / AC Type Ⅲ
Certifications and Standards
Grid Regulation
VDE4105, IEC61727/62116, VDE0126, AS4777.2, CEI 0 21, EN50549-1, G98, G99, C10-11, UNE217002, NBR16149/NBR16150
Safety EMC / Standard
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
General Data
Operating Temperature Range (℃)
-40~60℃, >45℃ Derating
Cooling
Smart cooling
Noise (dB)
<55 dB
Communication with BMS
RS485; CAN
Weight (kg)
35
Size (mm)
840W*345H*375D
Protection Degree
IP65
Installation Style
Wall-mounted
Warranty
5 years
Specification
Low Voltage Wifi Solar Inverter Deye SUN-5K-SG03LP1-EU 3.6kw 6kw 8kw For Solar System
Low Voltage Wifi Solar Inverter Deye SUN-5K-SG03LP1-EU 3.6kw 6kw 8kw For Solar System
Low Voltage Wifi Solar Inverter Deye SUN-5K-SG03LP1-EU 3.6kw 6kw 8kw For Solar System
Low Voltage Wifi Solar Inverter Deye SUN-5K-SG03LP1-EU 3.6kw 6kw 8kw For Solar System
Low Voltage Wifi Solar Inverter Deye SUN-5K-SG03LP1-EU 3.6kw 6kw 8kw For Solar System
Packing & Delivery
Low Voltage Wifi Solar Inverter Deye SUN-5K-SG03LP1-EU 3.6kw 6kw 8kw For Solar System
Low Voltage Wifi Solar Inverter Deye SUN-5K-SG03LP1-EU 3.6kw 6kw 8kw For Solar System
Low Voltage Wifi Solar Inverter Deye SUN-5K-SG03LP1-EU 3.6kw 6kw 8kw For Solar System
Low Voltage Wifi Solar Inverter Deye SUN-5K-SG03LP1-EU 3.6kw 6kw 8kw For Solar System
Low Voltage Wifi Solar Inverter Deye SUN-5K-SG03LP1-EU 3.6kw 6kw 8kw For Solar System


FAQ

A: What are your main products?
We have many series of solar products, mainly producing solar systems, solar panels, solar inverters, powerwall, solar lithium ion batteries,solar application solutions and solar mounting systems, and all related solar accessories.

B: Are you a factory or trading company?
We are a factory with more than nine years of experience in producing solar energy series products. You are welcome to visit our factory.

C: Can you support OEM and field installation?
Yes, as a professional solar system manufacturer, we can provide customers with OEM and on-site installation, comprehensive tech support, and after-sales services.

D: How does your factory conduct quality control?
Quality first. We have a professional QC team to control the quality strictly. Only when the quality meets the requirements, will it be packaged out of the factory.

E: What are your strengths in solar systems?
Fully automatic production line using international advanced production equipment such as Japan and Germany. The price and quality are very competitive, and we have cooperated with many well-known brands. And we can supply large solar energy series products.

F: How can I do if I need more help with the order?
You can chat with our sales online or send inquiry email, we will respond to you immediately. Any problem after delivery, we will offer you video call anytime, our engineer will also go to oversea help our customers if necessary.

G: Is sample available and free?
Sample will charge cost, but the cost will be refund after bulk order.

If you want to know more information, you can send inquiry to our team, we will cover more details.
