Specifications
Place of Origin :
Anhui, China
Brand Name :
Amosolar
Model Number :
Amosolar-MHP3/5KVA
Input Voltage :
24/48Vac
Output Voltage :
220/230/240Vac
Output Current :
80A
Output Frequency :
50Hz/ 60Hz
Output Type :
Single
Size :
130*295*455mm
Type :
DC/AC Inverters
Inverter Efficiency :
97%
Certificate :
CE/RHOS/IEC
Warranty :
3 years
Weight :
13KG
Product name :
Off Grid Inverter
Protection :
Short Circuit Overload Overvolt Overtemp
Application :
Residential Solar Power System
Rated power :
3000-5000W
Battery type :
Lead Acid \ Lithium \ Gel
Battery Voltage :
24/48v
MPPT voltage range :
60-115Vdc
OEM :
SUPPORT
Price :
$440.00/pieces 1-9 pieces
Description
Amsolar Off Grid System 3KW 5KW 8KW 10KW High Frequency Off-Grid Solar Inverter with 1
Amsolar Off Grid System 3KW 5KW 8KW 10KW High Frequency Off-Grid Solar Inverter with 1
Product Description
Model
Amosolar-MHP3KVA
Amosolar-MHP 4KVA
Amosolar-MHP 5KVA
Battery Voltage
24 VD
24 VD
48 VDC
INVERTER OUTPUT



Rated Power
3000VA/ 3000W
4000VA/ 4000W
5000VA/ 5000W
Parallel Capability
No
Yes, 6 units
Yes, 6 units
AC Voltage Regulation (Batt. Mode)
230VAC + 5%@ 50/60Hz
Surge Power
6000VA
8000VA
10000VA
Efficiency (Peak)
93%
93%
93%
Waveform
Pure sine wave
MPPT SOLAR CHARGER
Maximum PV Array Power
1800W
4500W
4500W
MPPT Voltage Range
30VDC ~ 80VDC
60VDC ~115VDC

Maximum PV Array Open Circuit Voltage
100VDC
145VDC

Maximum Solar Charge Current
50A
80A
80A
Maximum Efficiency
97%
AC CHARGER
Charge Current
30A
60A
60A
AC Input Voltage
230 VAC
Selectable Voltage Range
170-280 VAC (For Personal Computers); 90-280 VAC (For Home Appliances)
Frequency Range
50 Hz/60 Hz (Auto sensing)
AC BYPASS
Transfer Time
10 ms (For Personal Computers); 20 ms (For Home Appliances)
PHYSICAL
Dimension, Dx W x H (mm)
100 x272 x385
130 x 295 x 455
Net Weight (kgs)
7
11
11
OPERATING ENVIRONMENT
Humidity
15% to 95% Relative Humidity(Non-condensing)
0°C-55°℃Operating Temperature
0°C-55°℃
Storage Temperature
-15°℃ - 60°C
