590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
Specifications
Brand Name :
Amosolar
Model Number :
AMO565-590M10-144
Place of Origin :
China
Cell size :
182mmx182mm
Type :
Half Cell, N-TYPE, TOPCON
Panel Dimensions :
2279*1134*35mm
Panel Efficiency :
22.83%
Warranty :
30Years
Solar cell :
Mono 182*182mm
Cell Type :
N-type Mono-crystalline
Application :
Solar Power System
Junction Box :
IP68
Frame :
Anodized Aluminium Alloy
No. of cells :
144 (6*24) Cells
Max. Power :
590Watt
Weight :
28.6kg
OEM Order :
Acceptable
MOQ :
31 pieces
Price :
$60.00/pieces 31-203 pieces
Description
Company Profile
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
Amosolar_One Stop Solar Solution Supplier&Your Reliable Solar Partner
Are you looking for solar panels to start your business? We accept individual buyers,engineering installers, distributors, etc.To meet your various needs, Amosolar panel have a series of international authoritative certificates such as CE, TUV, IEC, INMETRO, CQC. Also accept OEM&ODM Services.
Maximum Power(Pmax)
565w
570w
575w
580w
585w
590W
Open-circuit Voltage (Voc)
52.69
52.81
52.93
53.05
53.17
53.29
Maximum Power Voltage(Vmp)
43.26
43.46
43.66
43.86
44.06
44.26
Short-circuit Current (Isc)
13.60
13.66
13.72
13.78
13.84
13.90
Maximum Power Current (Imp)
13.08
13.13
13.18
13.23
13.28
13.33
Solar Panel Efficiency
21.86%
22.06%
22.25%
22.44%
22.64%
22.83%
Junction Box
IP68
Frame
Anodized Aluminium Alloy
Weight
28.6kg
Power
565w-590w
Cell Type
N-type Mono-crystalline
Solar cell
Mono 182*182mm
OEM Order
Acceptable
Number of Cells
144 (6 * 24)
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
Amosolar solar panel have full line of international authoritative certificates such as CE, TUV, IEC, INMETRO, etc.
90+ countries where Amosolar PV modules have contributed to the zero-emission goal
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
SMARTER MANUFACTURING

Utilizingilizing fully automated manufacturing facilities
Advanced quality control system
Self-developed fully transparent quality management system.

ADVANCED TECHNOLOGY

Automated manufacturing facilities
Advanced quality control system
Self-developed fully transparent quality management system

590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
Quality Control

External Assessment
After Lamination,Check Each Panels
Make sure that the surface of eachsolar panel is complete, clean and correct.

EL Testing
Before and Following Lamination,Twice Testing Ensure no micro crack monitoring before final inspection, Continuousline monitoring
and video/photorecord for each cell and panel.

IV Testing
After Lamination,Conduct Electrical Performance Testing Simulate the real sunlight and testthe voltage and current of each solar
panel to ensure the efficiency of each solar panel.
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
590Watt Amosolar A Level 150mm N-type Solar Panel with 22.83% Efficiency from Chinese
