Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant
Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant
Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant
Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant
Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant
Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant
Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant
Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant
Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant
Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant
Specifications
Brand Name :
HNJZ
Model Number :
JL-5
Certification :
IS9001
Place of Origin :
China
MOQ :
1 set
Price :
USD 10000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50 set per month
Delivery Time :
25 days
Packaging Details :
Capacity : 5Tons/day, need 3*40HQ containers
Product :
USED ENGING OIL RECYCLING MACHINE
Capacity :
5TPD, 10TPD, 20TPD, 30TPD...300TPD
Working Type :
Continuous Working, Semi-Continuous Working
Automatic Degree :
Fully Automatic, Semi-Automatic
Applicable Material :
Crude Oil, Used Engine Oil, Waste Hydraulic Oil, Plastic Oil, Tyre Oil, Mixed Waste Oil, Other waste oil as customer required
Heating Fuel :
Fuel Oil, Natural Gas, Electric, Coal, Firewood
Reactor Material :
Q345R Steel Plate, Alloy Steel Plate
Final product :
diesel
Vacuum Degree :
-0.06-0.09MPa
Oil heating Temp :
175℃-400℃
Noise :
≤70dB
Description

tyre plastic to diesel oil recycling machine black ship fuel oil refining plant​

Project Details.
1. Used engine oil ,tyre pyrolysis oil , plastic oil , crude oil , sludge oil,furnace oil as input raw material.
2. Synthetic diesel as final product.
3. 10 ton distillation unit with latest integrated design, fast installation and easy operation.
4. Exclusive technology and Environmental friendly.
5. Heating fuel can be coal , wood , oil , gas and electricity.

SPECIFICATION OF WASTE OIL DISTILLATION PLANT
Capacity 3 TON , 5 TON , 10 TON , 30 TON ...
Working type batch type and contnuous type
Avaiable raw material Pyrolysis oil ,used motor oil , furnace oil , mixed waste oil , hydrulic oil , sludge oil etc.
Heating fuel coal , wood , pyrolysis oil , natural gas
Reactor raw material Q245R steel plate , Q345R boiler steel plate or customized support
Machine landing area 300-400 square meter (various by different capacity)
Operators 2 workers per shift
One batch time 17.5-21.5 hours
Life span 550-750 batches
Tyre feeding Auto-feeding
Space cover 300-400sqm
No.
End Production
Yield
Usage
1
Diesel
73%
Used for diesel engine
2
Gasoline
12%
Used for gasoline engine
3
Residue Oil
9%
* Feeding into Pyrolysis Machine for second Pyrolysis
* Sold directly for building road
4
Non-Condensible Gas
3%
Recycle as Heating fuel after treated by Gas-treatment System
5
Other
3%
* Water and impurity 2%
* Loss 1%

Distillation plant works as follows:
1. Pump waste oil into distillation reactor by oil pump.
2. Heat the reactor, and the liquid oil will slowly become oil gas, oil gas will go through catalytic chamber and condenser, then diesel will be cooled out first by controlling the temperature over 150 Celsius degrees.
3.The gasoline will be cooled out when the temperature is below 150 Celsius degrees, the rest of the system is same as pyrolysis system.

Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant

The pyrolysis oil with black color after distillation and remove color and smell , we will get synthetic diesel oil with yellow color , which can be used for diesel engines like trucks , tractors , ships etc.

Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant

Environment :

1. For water, it is used in two parts. In the cooling system, all the water is recycling, some water is evaporate due to high temperature, in some times, we just need to add water, no water emission. In the dedust system, the water is recycling, too.Due to the chemical reaction, the water is cleaned in the pool and recycled to dust removing device. No water emission.

2. About the gas, it includes two parts. First is the syngas, it is recycled to the furnance for heating, no emission. Another is the smoke, it is caused by the heating material. And it is clearned by water in the dedust system.NO emission, too.

3. About the carbon black, we do the futher process and our discharging system is fully closed, no slag flies out.No slag emission.

4. About the noise , we design draft fan with low noise and make it under international standard.

5. Above all, all the design can reach the international environmenal standard.
