Fully Continuous Waste Tyre Pyrolysis Plant To Oil And Carbon Black And Steel Wire
Fully Continuous Waste Tyre Pyrolysis Plant To Oil And Carbon Black And Steel Wire
Fully Continuous Waste Tyre Pyrolysis Plant To Oil And Carbon Black And Steel Wire
Fully Continuous Waste Tyre Pyrolysis Plant To Oil And Carbon Black And Steel Wire
Fully Continuous Waste Tyre Pyrolysis Plant To Oil And Carbon Black And Steel Wire
Fully Continuous Waste Tyre Pyrolysis Plant To Oil And Carbon Black And Steel Wire
Fully Continuous Waste Tyre Pyrolysis Plant To Oil And Carbon Black And Steel Wire
Fully Continuous Waste Tyre Pyrolysis Plant To Oil And Carbon Black And Steel Wire
Fully Continuous Waste Tyre Pyrolysis Plant To Oil And Carbon Black And Steel Wire
Fully Continuous Waste Tyre Pyrolysis Plant To Oil And Carbon Black And Steel Wire
Specifications
Brand Name :
HNJZ
Model Number :
30ton
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
USD 300000-800000 per set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
30 sets per month
Delivery Time :
45 days
Packaging Details :
naked package
Raw material :
Waste Tyre and Plastic, rubber
End product :
Fuel Oil ,Steel Carbon Black,Steel Wire
Name :
Fully continuous waste tyre/plastic/rubber prolysis plant
Working type :
Fully continuous
24 hour handling capacity :
30ton per day
24 hour oil production :
14T
Heating way :
Directly heating
Cooling way :
Water cooling
Water consumption :
10T/H
Noise :
≤85DB(A)
Area :
47*10*9M
Description

Fully Continuous Waste Tyre Pyrolysis Plant To Oil And Carbon Black And Steel Wire

Tyre pyrolysis plant adopt the latest pyrolysis technology. It can process the waste tyres or plastics with high temperature in a oxygen-free condition. Through the pyrolysis process, you can get fuel oil, carbon black, steel wire and combustible gas from waste tyres, or get fuel oil, carbon black and combustible gas from waste plastic. The whole process is safe and environmentally friendly. Our pyrolysis plant have two types: continuous and batch. Many waste plastics in our lives can use waste plastic pyrolysis plant to obtain fuel oil and carbon black, and most plastics have a higher oil yield than waste tires.For details, please contact our professional project manager for consultation.

Waste Material
Fianl Output
Tyres
1. 45%-50% crude oil
2. 10%-15% steel wire
3. 30% carbon black
Plastics
1. 50%-75% crude oil
2. 20%-45% carbon black
Rubbers
1. 50%-55% crude oil
2. 40%-45% carbon black
Appliacations of Tyre pyrolysis plant output products:
Output Products
Applications
Fuel Oil
* Can be directly sold to boiler factory, cement factory,glass factory etc.
* Can be refined to diesel by distillation machine.
* Used for heating.
Carbon black
* Can be directly sold to cement or brick factory.
* Pellet it used for heating.
Steel wire
* Directly sold to steel and scrap dealers.
* Treated by tire cutter before pyrolysis it, to get a cleaner and higher value steel wire.
Waste gas
* used for the heating and the smoke will be treated eco-friendly.

Specification

No
Specification
Fully continuous waste tyre/plastic/rubber prolysis plant
1
Model
HNJZ30
HNJZ40
HNJZ50
HNJZ60
2
Working type
Fully continuous
Fully continuous
Fully continuous
Fully continuous
3
Raw Material
Waste tires,waste rubber,waste plastic,waste acrylic,oily sludge
4
24 hour handling capacity
30T
40T
50T
60T
5
24 hour oil production
14T
18T
22T
27T
6
Heating way
Directly heating
Directly heating
Directly heating
Directly heating
7
Working pressure
Ordinary pressure
Ordinary pressure
Ordinary pressure
Ordinary pressure
8
Cooling way
Water cooling
Water cooling
Water cooling
Water cooling
9
Water consumption
10T/H
12T/H
16T/H
20T/H
10
Noise
≤85DB(A)
≤85DB(A)
≤85DB(A)
≤85DB(A)
11
Total weight
60T
68T
75T
80T
12
Area
47*10*9M
53*10*9M
55*10*9M
58*10*9M

Performance Feature

1). Continuous Operation
The latest continuous-feed system has a much bigger process capacity since it doesn’t require the starting and the stopping in the
pyrolysis reaction circle. The increased automation clearly has the big advantage of reduced downtime, reduced labor cost and increased efficiency over the batch feed generation

2)process material
waste tire, Oil field sludge, domestic waste plastic, industrial waste plastic, waste rubber and so on.
3) Raw material pretreatment
To keep continuous feeding and discharge system, it requires the waste tyres should be in small size. So before continuous pyrolysis process, the waste tires should be shredded into rubber powder.

Applications
It is applied to extract fuel oil from waste tires, rubbers, plastics, soles, life garbage, cable skin and so on .
seperating crude carbon black, steel wires. the sync gas produced can also be recycled to use as fuel to heat reactor, considerable cost of tire plastic plant.
