18 Kg Blue Poly Solar Panel Aluminium Alloy Frame For Household / Industry
18 Kg Blue Poly Solar Panel Aluminium Alloy Frame For Household / Industry
18 Kg Blue Poly Solar Panel Aluminium Alloy Frame For Household / Industry
18 Kg Blue Poly Solar Panel Aluminium Alloy Frame For Household / Industry
Specifications
Brand Name :
Yingli/Jinko
Certification :
ISO9001/CE
Place of Origin :
China
MOQ :
50 Pieces
Price :
Negotiation
Payment Terms :
T/T、L/C、West Union
Supply Ability :
5000000 Watt/Watts per Month
Delivery Time :
Shipped in 7 days after payment
Packaging Details :
In well protected carton or wooden box with pallets. 26pcs per pallet, 380pcs fill into 20GP, 820pcs fill into 40HQ
Operating Temperature :
-40° C~+85° C
Hs Code :
8541402000
Grade :
B
Product :
poly solar panel
Trademark :
Jinko
Package :
Carton; 2PCS/Carton
Description

Product Descriptio

280W Mono-crystalline silicon data sheet

Model Type

ZM-A-M-280

Nominal Maximum Power (Pmax)

280W

Optimum Operating Voltage (Vmp)

31.80V

Optimum Operating Current (Imp)

8.81A

Open Circuit Voltage(Voc)

38.00V

Short Circuit Current(Isc)

9.45A

Cell Type:

156mm x 156mm

Cell Arrangement

60 cells in series

Dimensions(mm)

1640 x 992 x 40 mm

Frame(Material Corners,etc.)

Anodized aluminium alloy

Maximum Series Fuse Rating

20A

Number of Bypass Diode

3

Module Efficiency

17.20%

Cell Efficiency(%)

19.20%

Weight (KG)

18.00KG

Power Tolerance

0 to +6W

Maximum System Voltage

DC 1000V

Front Glass Thickness(mm)

3.2mm

Junction- Box

IP67, 3 diodes

Cable

4mm (IEC) / 12AWG (UL), 900mm (650mm is optional)

Connectors

MC4 or MC4 compatible

Temperature Coefficient (Pmax)

-0.420% / °C

Temperature Coefficient (Voc)

-0.346% / °C

Temperature Coefficient (Isc)

0.065% / °C

Norminal Operating Cell Temperature

45.3 ± 2 °C

Temperature Range

-40°C to +85°C

Warranty

90% of 10 years,80% of 25 years.

Packing

carton or pallet

18 Kg Blue Poly Solar Panel Aluminium Alloy Frame For Household / Industry

Packaging & Shipping

18 Kg Blue Poly Solar Panel Aluminium Alloy Frame For Household / Industry18 Kg Blue Poly Solar Panel Aluminium Alloy Frame For Household / Industry

Applications

18 Kg Blue Poly Solar Panel Aluminium Alloy Frame For Household / Industry18 Kg Blue Poly Solar Panel Aluminium Alloy Frame For Household / Industry

FAQ

Q1. Can I have a sample order for led light?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than

Q3. Do you have any MOQ limit ?

A: 1pc for sample checking is available

Q4. How do you ship the goods and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5. How to proceed an order for led light?

A: Firstly let us know your requirements or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms the samples and places deposit for formal order.

Fourthly We arrange the production.

Q6. Is it OK to print my logo on led light product?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the products?

A: Yes, we offer 2-5 years warranty to our products.

Q8: How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system.

Secondly, during the guarantee period, we will send new lights with new order for small quantity. For

defective batch products, we will repair them and resend them to you or we can discuss the solution i

ncluding re-call according to real situation.
