Specifications
Brand Name :
Yingli/Jinko
Certification :
ISO9001/CE
Place of Origin :
China
MOQ :
50 Pieces
Price :
Negotiation
Payment Terms :
T/T、L/C、West Union
Supply Ability :
5000000 Watt/Watts per Month
Delivery Time :
Shipped in 7 days after payment
Packaging Details :
In well protected carton or wooden box with pallets. 26pcs per pallet, 380pcs fill into 20GP, 820pcs fill into 40HQ
Material :
Monocrystalline Silicon
Cell Grade :
A/B
Fram :
Aluminum Alloy
Condition :
New/Secondhand
OEM :
Avaliable
Trademark :
Yingli
Operating Temperature :
-40° C~+85° C
Hs Code :
8541402000
Description

High Quality Home Solar Power System 10KW Complete Set ,solar panel system with cheap price



Provide installation service, technical support
Buy our solar system products, Our installation team engineer can go your location to guide installing the solar system

Mission - Sincere, All-win, Unite, Aggressive.
Business Philosophy - People-oriented, Unite and Cooperation, Customer First, Reform and Innovation.
Values - To build first-class team, To create impressive performance, To struggle for the realization of dreams and corporate vision.


Why Choose Sunchees Products?


1) We has sold the system to Nigeria, Colombia, Burkina Faso, Egypt, Bolivia, Kenya, Ghana, South Africa, Argentina, Philippines, Congo, etc. Almost 85% of Africa countries !
2) With a professional installation team, Have went to Egypt, Chad, Nigeria, Ghana, Doha, Pakistan for installation
Our colleagues also are from African Sales Elite, they are good at polyglot language, we can be better service for our customers from all over the world.
3) Already started some inverter factories in some countries. so there is no problem in after sale service. And we are still looking for local factories in other countries, to unfolding depth of cooperation
4) We insist on using good quality raw material whenever and wherever.
We have offered many government projects in many countries. Our products are produced according to the quality of the government projects.
5) With customer's' praise as an assurance, Sunchees is a guaranteed brand.
6) Our company's philosophy is: one-stop solar energy service platform.

Technical Specifications:

Junhui Off grid solar power supply system- SP-10KW

System
Basic Information

Solar panel rated output power: 10KW
Suitable for daily power consumption : >40KWH
Allowable max loads power : 10KW
Full set:
Total volume:5.5CBM Total weight:2752KG

Solar panel

FS250W mono solar panel(poly optional)
Vmp:34.4V Voc:43.2V Imp 7.27A
Size : 1640*992*35mm
25 years life time (CE TUV)
Glass:3.2mm Tem pered
Terminal block:IP65 with MC4 connector
Efficiency performance :25 years 80 % 20 year 85% 10 years 90%
Ship free one for service

QTY
40pcs

PV Array Combiner

Model:H10T-96v Multiple PV strings inputs
Simplify wiring between PV array
and controller, protections to controller ,features:
Wide range of DC input voltage
Reliable thunderstorm& surge protection

QTY
1pc

Hybrid solar Inverter

Inverter power:10kw/96V
MPPT Controller model:96v/100A
Charging efficiency; 90%-95%,
LCD display inverter and controller info
Built-in AC charger (public network)
Output:110v,120v,220v,230v,240v(optional)
Product size: 590*470*730mm

QTY
1pc

Gel Battery

Capacity:12V/200AH
full sealed Solar power gel battery,
Service life:6-8 years ,
Size:522*240*219mm Weight:59KG
Connect way: 8pcs battery in series is each string. 4 string connect to solar hybrid inverter

QTY
32pcs

panel rack

Slope Rooftop or Flat rooftop
wind load:55m/s,snow load:1.5kn/m2
structure:Anodized Aluminum+stainless steel, Angle adjustable
(other type of rack can be customized as per client's requirement )

QTY
1set

Cables

1) 30pcs 16mm2*35CM battery cable
8pcs 16mm2*1M battery cable
2)4mm2 PV cable 150M
3)terminals and MC4

QTY
1set


Home solar system operating appliances' power load reference

Load reference

10KW solar home system

Load name

Load's watt

Qty

Total watt

lights

11W

20

220W

Fan

80W

4

320W

Computer(LCD display)

150W

2

300W

printer

250W

1

250W

Fax machine

150W

1

150W

refrigerator(200L)

120W

2

240W

Washing machine

300W

1

300W

Microwave

1500W

1

1500W

Electric cooker

300W

1

300W

Air conditioner(1HP)

750W

4

3000W

Satellite TV receiver/VCD

25W

1

25W

Color TV(32 inch)

150W

2

300W

Water pump

200W

1

200W

Total

7105W

Remark: Refrigerator, air conditioner &water pump is inductive load, start working power is 3-6 times more than normal power, in the process of use, turn on the inductive load first


Company Introduction:

Durable Second Hand Ying Lee Solar Panels 40 To 85 °C Operating Temperature


Products Packages:
Durable Second Hand Ying Lee Solar Panels 40 To 85 °C Operating Temperature

Successful Cases:

Durable Second Hand Ying Lee Solar Panels 40 To 85 °C Operating Temperature



FAQ:


Q: What can be included for this system from Us?
A:This system includes: solar panels, PV array combiner, Solar inverter with MPPT solar controller build in, Gel free maintenance battery, solar panel rack, cables.,etc.
Q: Is the solution for complete set? If not, what else are needed?
A: Yes, we can provide solution of complete set. If you don't need complete set, basic parts are available also.
Q: Is the system solution always the same? Can I customize one?
A: No. We have professional teams making solutions for our clients. Solutions are mainly customized based on different sunshine time and power consumption. So the 1kw system may be with different configuration.
Q: Who arranges the shipping?
A: We could help you arrange the shipment, we have good service forwarder in Foshan and Guangzhou.
Q: Can the inverter switch automatically to national grid to protect batteries.
A: Yes. It can also connect to third generator, as like diesel generator. Please tell our sales before production.
Q: What is the lifetime of the solar power system?
A: Solar panel's lifetime are 25 years, charger controllers 5~ 7 years, inverters 5~7 years, batteries 6~8 years.
Q:what is SUNCHEES solar system after sales service?
A: during the warranty ,Solar panel--ship free new one ;battery-ship the new one ,
Inverter/controller---ship free PCB by DHL or Fedex.
Q:what is your trade Assurance?
A:100% product quality protection
100% product on time shipment protection
100% payment protection for your covered amount
If you have more question, welcome to contact us freely, Choose SUNCHEES, Choose Satisfaction!
