18.3 Kg Second Hand Yingli Solar Panels 1640 × 990 × 35 Mm Format
18.3 Kg Second Hand Yingli Solar Panels 1640 × 990 × 35 Mm Format
Specifications
Brand Name :
Yingli/Jinko
Certification :
ISO9001/CE
Place of Origin :
China
MOQ :
50 Pieces
Price :
Negotiation
Payment Terms :
T/T、L/C、West Union
Supply Ability :
5000000 Watt/Watts per Month
Delivery Time :
Shipped in 7 days after payment
Packaging Details :
In well protected carton or wooden box with pallets. 26pcs per pallet, 380pcs fill into 20GP, 820pcs fill into 40HQ
Fram :
Aluminum Alloy
Condition :
New/SecondHand
OEM :
Avaliable
Trademark :
Yingli
Operating Temperature :
-40° C~+85° C
Cable :
4mm&Sup2
Description

Csun Poly Solar Panel 265W 270W with Yingli Solar Cell for Home Electricity

Product Description

MECHANICAL SPECIFICATION
Format 1640 × 990 × 35 mm
Weight 18.3kg
Glass White toughened safety glass, 3.2 mm
Backsheet Composite film
Frame Anodized aluminum profile
Cell Orientation 60 cells (6 × 10)
Junction Box Rated current 12A, IP 67,TUV&UL
Cable Length 900 mm, 1 × 4 mm²
Connector MC 4/ compatible with MC 4
ELECTRICAL CHARACTERISTICS
STC: Irradiance 1000W/m², Cell Temperature 25°C, Air Mass AM1.5. *Measuring tolerance: ±3%.
Power Class [W] 260 265
Power at MPP² PMPP [W] 260 265
Short Circuit Current* ISC [A] 8.95 9.01
Open Circuit Voltage* VOC [V] 37.7 37.8
Current at MPP* IMPP [A] 8.58 8.69
Voltage at MPP* VMPP [V] 30.3 30.5
Efficiency² η [%] ≥16.01 ≥16.01
WARRANTY
Please refer to product warranty for details
10 year Product Workmanship Warranty
25 year Linear Power Warranty

The power output shall not be less than 97.5% of the minimum power output stated in the product data sheet in the first year of the product's life cycle.The loss of power output shall not exceed 0.7% per year thereafter,ending with 80.7% in the 25th year.

QUALIFICATIONS AND CERTIFICATES

IEC61215/IEC61730/UL1703/IEC61701/IEC62716

ISO 9001: Quality Management System

ISO 14001: Environmental Management System

ISO14064: Greenhouse gases Emissions Verification

OHSAS 18001: Occupation Health and Safety

Management System

Packaging & Shipping
18.3 Kg Second Hand Yingli Solar Panels 1640 × 990 × 35 Mm Format
18.3 Kg Second Hand Yingli Solar Panels 1640 × 990 × 35 Mm Format

Our Services

1. ODM and OEM service.

2. Experienced and professional technical team and production team,sales team.

3. Strict quality control policy and management.

4. Excellent quality with reasonable price.

5. Fast delivery time

6. After sales service:7x 24 hours on line technical support

18.3 Kg Second Hand Yingli Solar Panels 1640 × 990 × 35 Mm Format
18.3 Kg Second Hand Yingli Solar Panels 1640 × 990 × 35 Mm Format
