Durable 60 Cell 300 Watt Solar Panel 900 Millimeter Cable Length For Household
Durable 60 Cell 300 Watt Solar Panel 900 Millimeter Cable Length For Household
Specifications
Brand Name :
Yingli/Jinko
Certification :
CE,TUV
Place of Origin :
China
MOQ :
50 Pieces
Price :
Negotiation
Payment Terms :
T/T、L/C、West Union, D/P
Supply Ability :
5000000 Watt/Watts per Month
Delivery Time :
Shipped in 7 days after payment
Packaging Details :
In well protected carton or wooden box with pallets. 26pcs per pallet, 380pcs fill into 20GP, 820pcs fill into 40HQ
Condition :
Stock
Cells :
60pcs
Meterial :
Polycrystalline Silicon
Grade :
C
Stock :
Yes
Description

C Grade Factory Stock Goods Solar Panels for for Pakistan Market

Product Description

Nominal power

Pm (Wp)

260-300W

Open circuit voltage

Voc (V)

45.72

Short-circuit current

Isc (A)

8.74

Voltage at max power

Vmp (V)

37.66

Current at max power

Imp (A)

8.08

Module efficiency

(%)

16.03

Cells efficiency

(%)

17.87

System Voltage

(V)

1000

Temp. coefficient Voc

(%; °C)

-0.35

Temp. coefficient Isc

(%; °C)

0.06

Temp. coefficient Pm

(%; °C)

-0.42

Operating temp.

(°C)

- 40 to +85

NOCT

(°C)

45±2


The electrical data apply to standard test conditions (STC): Irradiance of 1000 W/m2 with spectrum AM 1.5 and at cell temperature of 25°C.


Technical Date:

Junction box

6 bypass diodes, IP67

Wire cross section (Ø, mm2)

4.0

Cable lenght (mm)

900

Connector type

MC4/MC4 compatible

Dimensions (L x W x H, mm)

1950 x 992 x 50

Weight (kg)

23

Cell dimensions (mm)

152.4

No of cells / assembly

72 / 6 x 12

Type of cells

poly-crystalline

Hail resistance

Max. Ø 28 mm at 23 m/s

Wind load

2400Pa / 244kg / m²

Mechanical load

6000Pa / 612kg / m²


Durable 60 Cell 300 Watt Solar Panel 900 Millimeter Cable Length For Household

Power Range: Plus-Sorting 0 - 4,99Wp
PID Resistant: Potential Induced Degradation Free
Salt Mist Corrosion Resistant:Certified for salt rich environment
Sand Resistant:Certified for sand rich environment
Ammonia Resistant:Certified for ammonia rich environment
High Strengthened Design:Maximum mechanical load 6000 Pa
IP 67 Junction Box:Advanced water and dust proof level

Germany Quality:

AE Solar photovoltaic modules are characterized
by high-quality materials, best workmanship,
German development and management.

Plus Sorting:

Higher yield due to plus-sorting of 0 to +4.99 Wp
guarantees the highest system efficiency and
yield stability.
Liner Performance Guarantee:
With the linear performance guarantee of
30 years and a product warranty of 12 years,
AE Solar guarantees highest investment security and warranty claims.

Durable 60 Cell 300 Watt Solar Panel 900 Millimeter Cable Length For Household
Certificate:

Durable 60 Cell 300 Watt Solar Panel 900 Millimeter Cable Length For Household
