Reliable Solar Pv Modules , Mono Crystalline Solar Panel TUV Approved
Reliable Solar Pv Modules , Mono Crystalline Solar Panel TUV Approved
Specifications
Brand Name :
Yingli/Jinko
Certification :
ISO9001/CE
Place of Origin :
China
MOQ :
50 Pieces
Price :
Negotiation
Payment Terms :
T/T、L/C、West Union
Supply Ability :
5000000 Watt/Watts per Month
Delivery Time :
Shipped in 7 days after payment
Packaging Details :
In well protected carton or wooden box with pallets. 26pcs per pallet, 380pcs fill into 20GP, 820pcs fill into 40HQ
Application :
Industry
Color :
White, Black
Cell Grade :
A-Grade
Package :
Wooden Pallet&Carton
Operating Temperature :
-40° C~+85° C
Frame :
AI
Grade :
A-Grade Degree
Hscode :
8541402000
Description

305W 310W 315W 320W System Mono Crystalline Solar Panel PV Module with TUV Approved


Product Electricity Performance Parameters

Model

HN-PO-300W36

Cells tpye

Polycrystalline

Max power (Pmax)

300W

Max power voltage (Vmp)

17.4V± 3%

Max power current (Imp)

2.89A± 3%

Open circuit voltage (Voc)

21.8V± 3%

Short circuit current (Isc)

3.13A± 3%

Output tolerance

± 5%

Number of cells

36(4*9)

Cells size

156*52

Product Dimension(mm)
L*W*H

540*670*30*25

Weight(kg):

4


Temperature Characteristics

Norminal Operating Cell Temperature

45ºC(±2ºC)

Temperature Coefficiency of Pmax

-0.39%/ºC

Temperature Coefficiency of Voc

-0.32%/ºC

Temperature Coefficiency of Isc

0.05%/ºC

Maximum System Voltage

1000VDC

Power Tolerance

±0.03

Operating Temperature

-40ºC~+85ºC


Module warranty:

25 - year limited warranty of 80% power output;

10 - year limited warranty of 90% power output;

5 - year limited warranty of materials and workmanship.


Payment term:

1. 30% T/T in advance, paid the balance before shipment.


Package & Delivery:

1. Departure from Shanghai seaport by sea

2. 5 pcs in 1 carton


Delivery time:

7~10days after receiving payment for one container
